Окрашивание автомобиля 2023 цветные баллоны для

Окрашивание автомобиля 2023 цветные баллоны для

Категория: Spray Booths >>>
Поставщик: Shandong,Longxiang,Machinery,Co.,Ltd.

Цена:6 700,00 $ - 6 900,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	7973.59 $*	8372.43 $*
Aug-15-2025	7906.48 $*	8301.71 $*
Jul-15-2025	6633.55 $*	6965.94 $*
Jun-15-2025	7772.23 $*	8161.76 $*
May-15-2025	6767.23 $*	7105.30 $*
Apr-15-2025	7638.70 $*	8020.64 $*
Mar-15-2025	7571.42 $*	7950.51 $*
Feb-15-2025	7504.67 $*	7879.21 $*
Jan-15-2025	7437.86 $*	7809.46 $*

Характеристики

Products Description

LX2S
Outside size	7000×5350×3400mm(L×W×H)
Inside size	6900×3900×2650mm(L×W×H)
Entrance door	3 folds，3000x2600 mm(W×H), bending steel door,cast aluminum hinge, tempered glass window
Emergency door	6502000mm(WH),with pressure lock，with glass window，with step
Main System
Cabin system	Wall panel	-Sandwich style EPS 50mm,0.4mm thick steel, anti-flame and heat-insulation. -High quality galvanized steel roof panel.
Cabin system		Basement	-Galvanized steel assemble,280mm high,quadrate steel support,2 rows of grills,3 rows of indented plates. -2 ramps,external setting,6202000mm(WL)/pc
Ventilation system	Inlet fan	1*7.5KW turbo fan, air capacity: 28000m³/h, direct drive
		Outlet fan	1*7.5KW turbo fan, air capacity: 28000m³/h, direct drive
		Cabinet setting type	-Intake air from side upper ,adopt powder quadrate steel frame , strong and beautiful . -910mm height Air duct2 units -Elbow:90°1 unit
Heating system	Burner	Italy RIELLO G20 oil burner, heating capacity: 180000Kcal/h,heating time:6-8 min(20-60℃),fuel consumption is 5-8kg/vehicle with pneumatic damper
		Heat Exchanger	1.2mm thickness SUS304 stainless steel
		Cabinet	Rock wool interlayer, thermal insulation, flame retardant
Lighting system	Ceiling lights	84pcs16w LED lighting
Lighting system		Side lights	Optional
Filtering system	Primary filter	Grade G2 plate type , filtering rate＞83%
		Ceiling filter	EU5 grade high efficient filter,filtering rate＞98%
		Floor filter	Multi-layer fiberglass filter,filtering rate＞70%
Control system	Control panel	Intelligent control system
Control system		Function	Painting, risen-temperature painting, baking, time setting, lighting, failure indication, thermostatic switch, power switch, emergency stop
Voltage/Frequency	380V,50HZ,3 phase
Total power	16.5KW
