Цена:6 900,00 $ - 7 300,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-15-2025 8211.3 $* 8622.36 $*
Aug-15-2025 8142.3 $* 8549.43 $*
Jul-15-2025 6831.86 $* 7173.33 $*
Jun-15-2025 8004.97 $* 8404.51 $*
May-15-2025 6969.81 $* 7317.88 $*
Apr-15-2025 7866.26 $* 8259.95 $*
Mar-15-2025 7797.98 $* 8187.39 $*
Feb-15-2025 7728.20 $* 8114.85 $*
Jan-15-2025 7659.70 $* 8042.34 $*

Характеристики



Products Description


LX5
Outside size: 7000*5200*3400 mm (L*W*H)
Inside size: 6900*3900*2650 mm (L*W*H)
Entrance door: 3 folds,3000*2600 mm(W*H), bending steel door , Aluminum hinge, tempered glass window.
Emergency door: 650*2000mm(W*H),with pressure lock, observation window, one step.


Cabin system
Wall panel
-Sandwich style EPS 50mm,0.45mm thick colorful steel plate,anti-flame and heat-insulation.
-High quality galvanized steel roof panel.
Basement
-Galvanized steel assemble,280mm high,quadrate steel support,5 rows of grills with 30*4mm
-3 ramps, 970*2000mm(W*L)/pc
Ventilation system
Inlet fan
-Sandwich style EPS 50mm,0.45mm thick colorful steel plate,anti-flame and heat-insulation.
-High quality galvanized steel roof panel.
Outlet fan
1*7.5kw double-intake centrifugal fans,
air capacity:20000m³/h for each set
Cabinet setting type
-Intake air from side upper ,adopt powder quadrate steel frame , strong and beautiful .
-Cabinet for the fan*1unit ,air duct*2pieces,each piece is 910mm,
-Elbow:90°*1 unit
On-load airflow speed
0.4m/s,ventilation rate:315time/h
Heating system
Burner
Italy RIELLO RG5S oil burner, heating capacity: 260000Kcal/h, with pneumatic damper from spraying to baking cycle
Heat Exchanger
1.2mm thickness SUS304 stainless steel
Max.temperature
80℃，heating time:6-8min(20-60℃)，
fuel consumption is 6-8kg/vehicle
Cabinet
Rock-wool insulation*1 unit,
heat insulation and preservation,inflaming retarding
Lighting system
Ceiling lights
8*4pcs*16w LED lighting
Side lights
8*2pcs*16w LED lighting
Filtering system
Primary filter
Grade G2 plate type , filtering rate＞83%
Ceiling filter
EU5 grade high efficient filter,filtering rate＞98%
Floor filter
Multi-layer fiberglass filter,filtering rate＞70%
Control system
Control panel
Intelligent control system
Function
Lighting, temperature time setting, painting, constant temperature painting, baking,emergency stop, failure indication, time
accumulate, etc
Total power
16KW
Voltage/Frequency
380 V        50 HZ       3 phase
