Автомобильная камера для распыления индивидуальная разбрызгивания с боковым покрытием
- Категория: Spray Booths >>>
- Поставщик: Shandong,Longxiang,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 7616.18 $* | 7997.47 $* |
| Aug-15-2025 | 7552.92 $* | 7930.65 $* |
| Jul-15-2025 | 6336.48 $* | 6653.22 $* |
| Jun-15-2025 | 7424.13 $* | 7795.43 $* |
| May-15-2025 | 6464.76 $* | 6787.71 $* |
| Apr-15-2025 | 7296.15 $* | 7661.41 $* |
| Mar-15-2025 | 7232.79 $* | 7594.11 $* |
| Feb-15-2025 | 7168.97 $* | 7526.76 $* |
| Jan-15-2025 | 7104.38 $* | 7459.22 $* |
Характеристики
VR
Products Description
LX-D5 | |||||||
Outside size | 7000×5350×3400mm(L×W×H) | ||||||
Inside size | 6900×3900×2650mm(L×W×H) | ||||||
Entrance door | 3 folds, 3000x2600 mm(W×H), bending steel door | ||||||
Emergency door | 650*2000mm(W*H), equipped with handle lock | ||||||
Cabin system | Wall panel | --Sandwich style EPS 50mm, 0.45mm thick steel, anti-flame and heat- insulation. --High quality galvanized steel roof panel. | |||||
--Galvanized steel assemble, 280 mm high, with steel structure support, 5 rows of 30*5mm grills. --3 ramps, external setting, 970*2000mm(W*L)/pc | |||||||
Inlet fan | 1*7.5kw double-intake centrifugal fans, each set air capacity: 21000m³/h | ||||||
Outlet fan | 1*7.5kw double-intake centrifugal fans, each set air capacity: 21000m³/h | ||||||
--Intake air from side upper, adopt powder quadrate steel frame, strong and beautiful. --Cabinet for the fan*1unit, air duct * 2 units. --Elbow: 90°*1 unit. | |||||||
Airflow speed | On-load speed: 0.4m/s, ventilation rate: 315 times/h | ||||||
Heating system | Electric | Adopt High efficiency short wave infrared lamp, 10 sets of 3KW far-infrared lamp. Maximum operating temperature: 80℃. | |||||
Ceiling lights | 8units*4pieces*16w LED Lighting | ||||||
Side lights | 5units*2pieces*16w LED Lighting | ||||||
Primary filter | Grade G2 plate type , filtering rate＞83% | ||||||
Ceiling filter | EU5 grade high efficient filter, filtering rate＞98% | ||||||
Floor filter | Multi-layer fiberglass filter, filtering rate＞70% | ||||||
Control system | Control panel | Intelligent control system | |||||
Function | Lighting, temperature time setting, painting, constant temperature painting, baking, emergency stop, failure indication, etc | ||||||
Total power | 46 KW | ||||||
Voltage/frequency | 380V, 50HZ, 3phase | ||||||
Details Images
Why Choose Us
Product Process
Company Profile
Exhibition
Packaging&Shipping
FAQ
