Автомобильная покрасочная камера
Автомобильная покрасочная камера
Автомобильная покрасочная камера
Автомобильная покрасочная камера
Автомобильная покрасочная камера
Автомобильная покрасочная камера
Автомобильная покрасочная камера

Автомобильная покрасочная камера


Поделиться:


Цена:5 200,00 $ - 5 350,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-15-2025 6188.0 $* 6497.22 $*
Aug-15-2025 6136.16 $* 6443.44 $*
Jul-15-2025 5148.50 $* 5405.32 $*
Jun-15-2025 6032.63 $* 6334.0 $*
May-15-2025 5252.16 $* 5515.52 $*
Apr-15-2025 5928.74 $* 6224.63 $*
Mar-15-2025 5876.1 $* 6170.84 $*
Feb-15-2025 5824.68 $* 6115.22 $*
Jan-15-2025 5772.90 $* 6061.0 $*

Характеристики



Products Description


LX-D2
Outside size: 7000*5200*3400 mm (L*W*H)
Inside size: 6900*3900*2650 mm (L*W*H)
Entrance door: 3 folds,3000x2600 mm(W*H), bending steel door, aluminum hinge,tempered glass window
Emergency door: 650*2000mm(W*H),equipped with handle lock, observation window


Cabin system
Wall panel
-Sandwich style EPS 50mm,0.376mm thick color steel plate.
-High quality galvanized steel roof panel.
Basement
-Galvanized steel assemble,280mm high,quadrate steel support,3 rows of grills,2 rows of diamond plates
-2 ramps, 620*2000mm(W*L)/pc
Ventilation system
Inlet fan
2*3kw double-intake centrifugal fans, model: YDW4.5M1, air capacity:10000m³/h for each set
Outlet fan
Optional
Cabinet setting type
-Intake air from side upper ,adopt powder quadrate steel frame , strong and beautiful .
-Cabinet for the fan*1unit ,air duct:2*910mm,
-Elbow:90°*1 unit
airflow speed
On-load airflow speed:0.3m/s,
ventilation rate:260times/h
Heating system
Electric heating
Adopt infrared heating system, 10 sets of 3KW single door far-infrared lamp. Maximum operating temperature: 80℃, heating rate
(20-80℃) : 15-20min.
Lighting system
Ceiling lights
8*4pcs*16w LED lighting
Side lights
optional
Filtering system
Primary filter
Grade G2 plate type , filtering rate＞83%
Ceiling high efficient filter
EU5 grade high efficient filter,filtering rate＞98%
Control system
Control panel
Intelligent control system
Function
Lighting, temperature time setting, painting, constant temperature painting, baking,emergency stop, failure indication, time
accumulate, etc
Total power
37KW
Voltage/Frequency
380 V    50 HZ     1 phase


Details Images








Why Choose Us






Product Process




Company Profile














Exhibition






Packaging&Shipping




FAQ
