2023CE распылительная камера для окраски автомобиля надувная
- Категория: Spray Booths >>>
- Поставщик: Shandong,Longxiang,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 6069.8 $* | 6372.42 $* |
| Aug-15-2025 | 6018.85 $* | 6319.27 $* |
| Jul-15-2025 | 5049.44 $* | 5301.17 $* |
| Jun-15-2025 | 5916.54 $* | 6212.38 $* |
| May-15-2025 | 5151.91 $* | 5409.37 $* |
| Apr-15-2025 | 5814.9 $* | 6105.92 $* |
| Mar-15-2025 | 5763.92 $* | 6051.16 $* |
| Feb-15-2025 | 5712.3 $* | 5998.94 $* |
| Jan-15-2025 | 5661.57 $* | 5944.36 $* |
Характеристики
Products Description
LX-D2 | ||||||||
Outside size: 7000*5200*3400 mm (L*W*H) | Inside size: 6900*3900*2650 mm (L*W*H) | |||||||
Entrance door: 3 folds,3000x2600 mm(W*H), bending steel door, aluminum hinge,tempered glass window | ||||||||
Emergency door: 650*2000mm(W*H),equipped with handle lock, observation window | ||||||||
Cabin system | Wall panel | -Sandwich style EPS 50mm,0.376mm thick color steel plate. -High quality galvanized steel roof panel. | |||||
Basement | -Galvanized steel assemble,280mm high,quadrate steel support,3 rows of grills,2 rows of diamond plates -2 ramps, 620*2000mm(W*L)/pc | ||||||
Ventilation system | Inlet fan | 2*3kw double-intake centrifugal fans, model: YDW4.5M1, air capacity:10000m³/h for each set | |||||
Outlet fan | Optional | ||||||
Cabinet setting type | -Intake air from side upper ,adopt powder quadrate steel frame , strong and beautiful . -Cabinet for the fan*1unit ,air duct:2*910mm, -Elbow:90°*1 unit | ||||||
airflow speed | On-load airflow speed:0.3m/s, ventilation rate:260times/h | ||||||
Heating system | Electric heating | Adopt infrared heating system, 10 sets of 3KW single door far-infrared lamp. Maximum operating temperature: 80℃, heating rate (20-80℃) : 15-20min. | |||||
Lighting system | Ceiling lights | 8*4pcs*16w LED lighting | |||||
Side lights | optional | ||||||
Filtering system | Primary filter | Grade G2 plate type , filtering rate＞83% | |||||
Ceiling high efficient filter | EU5 grade high efficient filter,filtering rate＞98% | ||||||
Control system | Control panel | Intelligent control system | |||||
Function | Lighting, temperature time setting, painting, constant temperature painting, baking,emergency stop, failure indication, time accumulate, etc | ||||||
Total power | 37KW | ||||||
Voltage/Frequency | 380 V 50 HZ 1 phase | ||||||
Details Images
Why Choose Us
Product Process
Company Profile
Exhibition
Packaging&Shipping
FAQ
