Стенд с открытым лицом для сухой
- Категория: Spray Booths >>>
- Поставщик: Yancheng,Biaosin,Import&Export,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.64 $* | 0.68 $* |
| Aug-18-2025 | 0.59 $* | 0.37 $* |
| Jul-18-2025 | 0.96 $* | 0.27 $* |
| Jun-18-2025 | 0.42 $* | 0.42 $* |
| May-18-2025 | 0.40 $* | 0.48 $* |
| Apr-18-2025 | 0.34 $* | 0.72 $* |
| Mar-18-2025 | 0.47 $* | 0.80 $* |
| Feb-18-2025 | 0.48 $* | 0.74 $* |
| Jan-18-2025 | 0.54 $* | 0.43 $* |
Характеристики
Details Images
Product Description
Specification
Outside Dimension (mm) | 18156*6906*5800(L*W*H) | Inside Dimension(mm) | 18000*5000*5000(L*W*H) | ||||
Front Door(mm) | 4000*4500(W*H) 4 folds | Service Door (mm) | 800*2000(W*H)*2 | ||||
Total Power | 105KW | ||||||
Cabin System | Wall panel | 75mm EPS sandwich panel, steel sheet thickness: 0.6mm | |||||
Ceiling panel | 50mm rock-wool sandwich panel | ||||||
Basement | Dig 2 row of pits basement | ||||||
Windows | 5mm safety tempered glass | ||||||
Air Make-up System | Air inlet fan system | 6*7.5kw centrifugal fan | |||||
Exhaust fan system | 3*18.5kw belt drive centrifugal fan | ||||||
Total air inlet capacity | 108000m3/h | ||||||
Total air exhaust capacity | 105000m3/h | ||||||
Air capacity control | Air inlet system and exhausted system, each with 1 manual damper | ||||||
Exhaust duct | Each exhaust fan with 1*6 meters straight ducting, one 90°elbow and one 45°elbow. | ||||||
Purification System | Pre-filter | G3 grade | |||||
Ceiling filter | EU5 / F5 | ||||||
Floor filter | Green fiber glass filter / G3 grade | ||||||
Exhausted fan filters | Fiber glass filter and active carbon | ||||||
Heating System | Heat exchanger | SUS304 material, argon arc welding. | |||||
Heating burner: | 3sets Riello RG5S diesel burner | ||||||
Heating productivity | 260000Kcal/h*3 | ||||||
Spray to baking switch | 20N BELIMO brand electrical damper | ||||||
Chimney ducting | Each heating system with 1* 6 meters stainless ducting and one chimney elbow | ||||||
Max heating temperature | 80℃ | ||||||
Fuel consumption | 10-15L/vehicle | ||||||
Lighting System | Ceiling lights | 24 Units, each 4 * 18W LED lamps. Total 1728 W | |||||
Side lights | 24 Units, each 2 * 18W LED lamps. Total 864 W | ||||||
Illumination | 900LUX | ||||||
Controlling System | Switched control panel | Spraying & baking switch, before baking flash-off, after baking flash off, lighting switch, emergency stop, breakdown alarm, failure alarm | |||||
