Поделиться:


Цена:758,22 ₽*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-19-2025 902.73 $* 947.24 $*
Aug-19-2025 894.63 $* 939.10 $*
Jul-19-2025 750.35 $* 788.68 $*
Jun-19-2025 879.28 $* 923.29 $*
May-19-2025 766.27 $* 804.55 $*
Apr-19-2025 864.0 $* 907.48 $*
Mar-19-2025 857.19 $* 900.30 $*
Feb-19-2025 849.57 $* 891.97 $*
Jan-19-2025 841.88 $* 883.77 $*

Характеристики

More Meanwell led power supply:

Meanwell AC DC Single Output LPV-60-24 Sealed Panel Mount smps 24vdc 24V 24 volts Power Supply


   Features:

  • Constant Voltage (CV) mode output
  • Universal AC input / Full range
  • Withstand 300VAC surge input for 5 seconds
  • Protections: Short circuit/ Over load/ Over voltage
  • Fully encapsulated with IP67 level
  • Fully isolated plastic case
  • Cooling by free air convection
  • class II power unit, no FG
  • Pass LPS
  • Suitable for LED-based decorative/architectural lighting,LED stage, theater lighting,
  • and LED electronic displays
  • 100% full load burn-in test
  • Low cost, high reliability
  • 2 years warranty

Models:

Module  DC voltage Rated current Current range Rated power Input voltage Effic.
LPV-60-5 5V 8A 0 ~ 8A  40W

90 ~ 264VAC

127 ~ 370VDC

 76%
LPV-60-12 12V 5A 0 ~ 5A  60W 83%
LPV-60-15 15V 4A 0 ~ 4A  60W 83%
LPV-60-24 24V 2.5A 0 ~ 2.5A  60W 86%
LPV-60-36 36V 1.67A 0 ~ 1.67A 60W 86%
LPV-60-48 48v 1.25A 0 ~ 1.25A 60W 86%



View detail information about the item,Please send quote request



Much more models:

Model LPH-18 LPV-20 LPV-35 LPV-60 LPV-100 LPV-150

AC input

voltage range

 180 ~ 264Vac  90~264VAC 90~264VAC; 127~370VDC LPV-150: 180~305VAC; 254~431VDC
LPVL-150: 90~132VAC; 127~370VDC

AC

inrush current (max.)

 Cold start,
50A at 230VAC		 Cold start,
70A at 230VAC		 Cold start,
55A at 230VAC		 Cold start, 60A at 230VAC Cold start, 75A at 230VAC LPV-150: Cold start, 60A at 230VAC
LPVL-150: Cold start, 75A at 115VAC
Over voltage protection 115%~135% rated output voltage 110%~150% hiccup mode, auto-recovery
Working temperature -30~+70°C -30~+65°C -30~+70°C -25~+70°C -25~+65°C
EMC standards

EN55032 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11,

FCC part 15 class B (LPL-18)

 EN55032 class B, EN61000-3-2 class A, EN61000-3-3, EN61000-4-2,3,4,5,6,8,11;
FCC part 15 for LPVL-150 only
Dimension (LxWxH)(mm) 140x 30x 22 118x 35x 26 148x 40x 30 162.5x 42.5x 32 190x 52x 37 191x 63x 37.5
Packing 70pcs/13.3Kgs 0pcs/14.2Kg 40pcs/14.6Kg 32pcs/13.8Kg/ 20pcs/13.6Kg

LPV-150: 20pcs/15.8Kg

LPVL:50:20pcs/17Kg



 View detail information about the item,Please send quote request

Details-LPV-35

More requirement about the item,Please send quote request


More requirement about the item,Please send quote request


                 More requirement about the item,Please send quote request

LPV series

More requirement about the item,Please send quote request

Guarantee

More requirement about the item,Please send quote request
