Лидер продаж 2021 OEM ODM 2 года гарантии светодиодный драйвер 60 Вт 12 В для мебели светодиодное
- Категория: Светодиодный драйвер >>>
- Поставщик: Zhuhai,Pt,Power,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 5.71 $* | 5.2 $* |
| Aug-19-2025 | 5.43 $* | 5.6 $* |
| Jul-19-2025 | 4.3 $* | 4.99 $* |
| Jun-19-2025 | 5.6 $* | 5.37 $* |
| May-19-2025 | 4.31 $* | 4.86 $* |
| Apr-19-2025 | 5.37 $* | 5.87 $* |
| Mar-19-2025 | 5.40 $* | 5.25 $* |
| Feb-19-2025 | 4.30 $* | 4.73 $* |
| Jan-19-2025 | 4.79 $* | 4.32 $* |
Характеристики
Product Features:
* Constant Voltage design(CV Mode)
* Universal AC input
* Sealed inside with plastic irrigation. Conform with IP33 rating.
* Withstand 300VAC surge input for 5 seconds
* Built-in Protections: Short circuit/Overload
* Cooling by free air convection
* 100% Full Load Burn-in Test
* High performance
* 2-Years warranty; replacement upon rejection during warranty period.
* Universal AC input
* Sealed inside with plastic irrigation. Conform with IP33 rating.
* Withstand 300VAC surge input for 5 seconds
* Built-in Protections: Short circuit/Overload
* Cooling by free air convection
* 100% Full Load Burn-in Test
* High performance
* 2-Years warranty; replacement upon rejection during warranty period.
Model No.： | PV-12060P-S | PV-24060P-S | ||||||||||
Rated Output Voltage | 12V | 24V | ||||||||||
Output current Range | 0-5A | 0-2.5A | ||||||||||
Rated Output Power | 60W | |||||||||||
Output Voltage Precision | ±3% | |||||||||||
Output Ripple and Noise | ＜240mVP-P | 480mVP-P | ||||||||||
Load Regulation | ±2% | |||||||||||
Start/Rise Time | <1000ms/230VAC | |||||||||||
Retention Time | 20ms/230VAC | |||||||||||
Input Voltage Range | 100-240VAC | |||||||||||
Input Frequency Range | 50-60HZ | |||||||||||
Power Efficiency | >86% | |||||||||||
Leak Current | ＜3mA/230VAC | |||||||||||
Overload Protection | When the load current exceeds 110-150% of the output current, the power supply will enter protection state. Protection Mode: Hiccup Mode. | |||||||||||
Short Circuit Protection | Protection mode: Hiccup Mode. When the short-circuit fault is removed, the power supply will automatically resume work. | |||||||||||
Working Temperature | -30℃-65℃ ( pls refer to "Derating Curve" in below Graph） | |||||||||||
Storage Temperature | -40℃-80℃ | |||||||||||
Ingress Protection Rating | 90%RH non condensing, refer to IP33 | |||||||||||
Shockproof Character | 10-500HZ,2G 10min/1cycle,preiod for 60min,each along X,Y,Z axes | |||||||||||
Temperature Coefficient | ±0.03%℃ (0-50℃) | |||||||||||
Security Standard | IEC 61347-2-13 2014+A1 IEC 61347-1 2015+A1 | |||||||||||
Withstand Voltage | I/P-O/P:1.5KVAC | |||||||||||
Insulation Resistance | I/P-O/P:>100M Ohms/500VDC/25℃/70% RH | |||||||||||
Outter Size | 185*63.5*22mm(L*W*H) | |||||||||||
Weight/PCS | 190g | |||||||||||
