UE-220 2020 новые дешевые товары из Китая портативный измеритель автомобильной краски для камеры окрашивания распылением машина оборудование покраски автомобилей цена

UE-220 2020 новые дешевые товары из Китая портативный измеритель автомобильной краски для камеры окрашивания распылением машина оборудование покраски автомобилей цена

Цена:*

Количество:

Outside Dimension (mm)	7000×5250×3400	Inside Dimension(mm)	6900×3900×2650
Front Door(mm)	3000×2600(W*H)	Service door(mm)	800×2000(W*H)
Total Power	15kw
Cabin system	Front door	3 folded sheet metal door, double side with PU insulated
		Wall panel	50mm EPS sandwich panel, steel sheet thickness: 0.476mm
		Ceiling panel	Galvanized steel sheet
		Basement	300mm depth construction galvanized basement, two rows galvanized grids,three rows checkered plates.
		Ramps	For option
		Door glass	5mm tempered glass
Air make-up system	Air inlet fan system	2 sets 4kw centrifugal fan, fan model: YDW-4.5L
		Exhausted fan system	1 set 5.5kw centrifugal fan, fan model: YDW-5.6S
		Air inlet capacity	24000m³/h
		Exhuasted capacity	15000m³/h
		Exhausted ducting	Four meters straight galvanized ducting and one 135 degrees elbow
Purification system	Pre-filter	G3 grade
		Ceiling filter	600G filter EU5 / F5
		Floor filter	Fiberglass filter
		Exhausted filter	Filber glass and carbon filter
Heating system	Heat Exchanger	SUS304 200KW stainless heating exchanger
		Heating burner	Riello G20 diesel oil burner
		Heating productivity	20000Kcal/hour
		Spray to baking switch	Pneumatic damper
		Chimney ducting	4 meters chimney and one chimney elbow
		heating temperature	Maximum 80℃
		fuel consumption	6-8L/vehicle
Lighting system	Ceiling lighting	8 Units, each 4 * 24W LED lamps.
		Side lighting	For option
		Illumination	1000LUX
Control system	Switch controlling system	Spraying & baking switch, lighting switch, timer , temperature controlling switch, emergency stop, breakdown alarm, failure alarm, pressure gauge
