CE 75W 230VAC вход 24VDC выход Triac затемнение постоянного напряжения светодиодный
- Категория: Светодиодный драйвер >>>
- Поставщик: Ever,Shining,Optotech,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-17-2025 | 19.96 $* | 19.93 $* |
| Jul-17-2025 | 15.28 $* | 15.26 $* |
| Jun-17-2025 | 19.62 $* | 19.49 $* |
| May-17-2025 | 19.41 $* | 19.72 $* |
| Apr-17-2025 | 15.40 $* | 15.20 $* |
| Mar-17-2025 | 18.83 $* | 18.18 $* |
| Feb-17-2025 | 18.80 $* | 18.2 $* |
| Jan-17-2025 | 18.26 $* | 18.84 $* |
Характеристики
Products Description
Model No. | LD060D-VE50012-M40 | LD075D-VE32024-M40 | ||||||
Output | DC Voltage Range | 12V | 24V | |||||
Rated Current | 0~5000mA | 0~3200mA | ||||||
Rated Max. Power | 60W | 75W | ||||||
Dimming Range | 1%-100% | 5%-100% | ||||||
Voltage Tolerance | 0.05 | 0.05 | ||||||
Ripple & Noise (Max.) note.2 | 1.2 Vp-p | 2.6 Vp-p | ||||||
Efficiency note.1 full load | >83% | >83% | ||||||
Set up Time (Max) | 0.5S / 230Vac at full load | |||||||
Input | Rated Voltage | 207 - 254VAC | ||||||
Frequency Range | 50/60Hz | |||||||
AC Current (Max.) | 0.7A at 230Vac | |||||||
Power Factor | > 0.5 at 230Vac with full load. | |||||||
Inrush Current (Max.) | ≤ 60A at 230Vac | |||||||
Leakage Current | < 1mA / 230Vac | |||||||
Connection | Input | UL rated, 18 AWG x 2 C( 150 mm) | ||||||
Output | UL rated, 18 AWG x 2 C( 150 mm) ,(Vo+, Vo-,) | |||||||
Others | MTBF | 100K hours min. @Ta=25℃ | ||||||
Dimension (L*W*H) | 137.5 * 47 * 32 mm | |||||||
Packing (L*W*H) / Carton | 340 * 305 * 200 mm; 50pcs/ 19 Kg | |||||||
More Product
Company Profile
Certifications
Product Process
Product packaging
FAQ
Q1: What is your MOQ of LED Driver ?
A : MOQ 100pcs
Q2: How many years warranty of your LED Driver ?
A: 3~5 years warranty
Q3: What is your standard lead time ?
A: 3 days for samples and 2~3 weeks for mass production
Q4: Do you have any certifications of your LED Driver ?
A: We have obtained UL/ cUL/ CE/FCC /TUV/CCC/KC/CB/SAA certificates to meet different martket requirements
Q5: Do you have LED Driver factory?
A:Yes ,We are OEM&ODM manufacturer in Dongguan and headquarter in Taiwan
A : MOQ 100pcs
Q2: How many years warranty of your LED Driver ?
A: 3~5 years warranty
Q3: What is your standard lead time ?
A: 3 days for samples and 2~3 weeks for mass production
Q4: Do you have any certifications of your LED Driver ?
A: We have obtained UL/ cUL/ CE/FCC /TUV/CCC/KC/CB/SAA certificates to meet different martket requirements
Q5: Do you have LED Driver factory?
A:Yes ,We are OEM&ODM manufacturer in Dongguan and headquarter in Taiwan
