Квилтер для мебели и домашнего текстильного
- Категория: Quilting Machines >>>
- Поставщик: Dongguan,New,Hengchang,Intelligent,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.42 $* | 0.98 $* |
| Aug-18-2025 | 0.85 $* | 0.66 $* |
| Jul-18-2025 | 0.16 $* | 0.33 $* |
| Jun-18-2025 | 0.61 $* | 0.31 $* |
| May-18-2025 | 0.91 $* | 0.98 $* |
| Apr-18-2025 | 0.81 $* | 0.26 $* |
| Mar-18-2025 | 0.84 $* | 0.91 $* |
| Feb-18-2025 | 0.97 $* | 0.80 $* |
| Jan-18-2025 | 0.64 $* | 0.31 $* |
Характеристики
Product Description
Product Application
Mattress panel, mattress pads, bedspreads, comforters, bedding, upholstery, and etc.
Mattress panel, mattress pads, bedspreads, comforters, bedding, upholstery, and etc.
HC-D3000 Technical Specification | ||||||
Quilt width | ≤2400mm | |||||
Quilting thickness | ≤80mm | |||||
Needle size | DP*17 21#/22#/23# | |||||
Stitch | 2-6mm | |||||
Rotation speed | 3000RPM | |||||
Production speed | 40-160m/h | |||||
Power | 10.5KW | |||||
Voltage | 3-Phase 380V/50HZ3-Phase 220V/60HZ | |||||
Weight | 5000KG | |||||
Size(L*W*H) | 10000*4500*1600mm | |||||
Special Function
• Advanced qualified lock stitch sewing head, rotating speed can be up to 3000RPM.
• Diagnostic testing for thread broken and pattern compensation.
• Adjustable presser plate in different thickness.
• Memories restart all patterns after stop quilting.
• 360° T&J and simple pattern, more than 200 patterns.
• Capable pattern-designing software can adopt various quilting file and quilting system.
• Daily output counter and total output counter.
• Needle arrangement and pattern showing.
• Automatic needle lift,pneumatic thread cutting and thread break detector.
• Pattern compensation and correction.
• Panasonic servo control system.
• Automatic material feeding and cutting device.
• Special left sewing head design, patented product.
• Advanced qualified lock stitch sewing head, rotating speed can be up to 3000RPM.
• Diagnostic testing for thread broken and pattern compensation.
• Adjustable presser plate in different thickness.
• Memories restart all patterns after stop quilting.
• 360° T&J and simple pattern, more than 200 patterns.
• Capable pattern-designing software can adopt various quilting file and quilting system.
• Daily output counter and total output counter.
• Needle arrangement and pattern showing.
• Automatic needle lift,pneumatic thread cutting and thread break detector.
• Pattern compensation and correction.
• Panasonic servo control system.
• Automatic material feeding and cutting device.
• Special left sewing head design, patented product.
Company Introduction
Packing & Delivery
Packaging | ||
Size | Wooden box:4800×2300×2200mm | |
Weight | 4.5T | |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated. | |
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* View our Factory.
* Inquiry and consulting support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Certifications
