Характеристики
Machine recommend
INFO
HX-50A Series fitted with a smooth-running, robust chain conveyor, which ensures reliable,accurate product transfer from station to station as well as maximum machine uptime.Rapid high-yield, labor-saving,most popular in blister packaging
| Model | HX-50A-9 | HX-50A-10 | HX-50A-12 |
| Packing Size (mm) | 500*300 | 600*400 | 600*400 |
| Stroke adjustment | 100 | 100 | 100 |
| mold station | 9 | 10 | 12 |
| Production capacity(s/cycle) | 8 | 8 | 8 |
| Power | 380V,3KW | 5KW | 6KW |
| Machine dimension(mm) | L2500*W660*H1640 | L3000*W870*H1640 | L3600*W870*H1640 |
| Machine Weight(Kg) | 400 | 500 | 600 |
| PLC Touchscreen | N/A | . | . |
| Finished Unloader | N/A | . | . |
| Card Feeder | N/A | . | . |
| Drive Type | CAM indexers | CAM indexers | Servo moto |
Features
1. Flexible machine concept for the efficient packaging of different formats
2. Sealing performance
3. Low capital costs
4. Very high cycle rate
5. Robust chain conveyor for maximum machine uptime
6. Servo-regulated drives ensure smooth running
7. PLC Control easy to operate and maintence
8. 9 or 12 station for optional
9. Finished unloader / robot arm.
10. Heavy-duty industrial design and construction for trouble-free service & long life
11. Custom machine sizes and features quoted on request
Typical Application
Blister packs are used to package products such as toys, hardware, medication, etc.
Detailed parts
Card feeder suck Automatic card feeder
finished unloader/ robot hand
A, Robust chain conveyor for maximum machine uptime
B, Mold locked on the table
C, Electrical part design and installation is standard, be equipped with quick-stop function
D, The pressure plate is very elastic and sealing products is close together.
E, Working size can be customized
B, Mold locked on the table
C, Electrical part design and installation is standard, be equipped with quick-stop function
D, The pressure plate is very elastic and sealing products is close together.
E, Working size can be customized
Packing
1. Wooden box or wooden frame, box: 30 USD/CBM, wooden frame: 15 USD/CBM;
2. Woodwork will be fumigated in many country;
3. If container too tightly, we only use PE- film for packing or pack it according to customers special request.
4. Machines will be Split to facilitate placement.
