Автоматическая высокочастотная сварочная и режущая машина для упаковки аккумуляторных щеток в блистерной
- Категория: Blister Packaging Machines >>>
- Поставщик: Shenzhen,Hansweld,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.5 $* | 0.69 $* |
| Aug-15-2025 | 0.63 $* | 0.90 $* |
| Jul-15-2025 | 0.7 $* | 0.26 $* |
| Jun-15-2025 | 0.37 $* | 0.86 $* |
| May-15-2025 | 0.11 $* | 0.51 $* |
| Apr-15-2025 | 0.51 $* | 0.94 $* |
| Mar-15-2025 | 0.67 $* | 0.40 $* |
| Feb-15-2025 | 0.35 $* | 0.54 $* |
| Jan-15-2025 | 0.1 $* | 0.57 $* |
Характеристики
Product Parameter
Application:
Used for sealing packaging of double-sided blister blister of APET, PETG, GAG environmentally friendly materials, blister paper card packaging, toothbrush sealing packaging,
welding and fusing with EVA cloth leather, leather, OPP, and PU materials, also can be used It is used in the production of
flexible lines (SK lines) for APET, PETG, PVC, and PP sheets.
welding and fusing with EVA cloth leather, leather, OPP, and PU materials, also can be used It is used in the production of
flexible lines (SK lines) for APET, PETG, PVC, and PP sheets.
Equipment characteristics:
1. European-style electric box, strong and stable high-frequency output;
2. Double sliding table, high efficiency;electric propulsion of left and right sliding table;
3. Ultra-long high-cycle output time, no electrical parts burned, durable;
4. Originated from Europe, automatic high-cycle technology;
5. Special shielding treatment, the human body radiation is small;
6. The electron tube is equipped with an independent fresh air cooling system;
7. High-frequency synchronous fusing, one-time forming;
8. Use microcomputer touch screen to control PLC numerical control programming system.
2. Double sliding table, high efficiency;electric propulsion of left and right sliding table;
3. Ultra-long high-cycle output time, no electrical parts burned, durable;
4. Originated from Europe, automatic high-cycle technology;
5. Special shielding treatment, the human body radiation is small;
6. The electron tube is equipped with an independent fresh air cooling system;
7. High-frequency synchronous fusing, one-time forming;
8. Use microcomputer touch screen to control PLC numerical control programming system.
POWER | 5KW | 8KW | 10KW | 12KW | 15KW | ||||
Power Supply | 220V/380V 50/60Hz | ||||||||
Frequency | 27.12 Mhz | ||||||||
Input Power | 8KVA | 15KVA | 18KVA | 20KVA | 25KVA | ||||
Rectifier | Silicon Diode | ||||||||
Max Gap Between Electrode | Standard:200mm( Customized Acceptable) | ||||||||
Moving Stoke | Standard:150mm( Customized Acceptable) | ||||||||
Oscillator Model | 7T85RB | 7T69RB | E3069 | E3010 | 8T85RB | ||||
Size of Sealing Plate(Shuttle-way Style) | 200*350mm | 350*450mm | 400*600mm | 550*600mm | 600*700mm | ||||
Heating System | 30-200℃ Adjustable | ||||||||
Sealing Time | 0-10S Adjustable | ||||||||
Productivity | ≤4000 opearation circle/8 hours | ||||||||
