1 лист * 8 шт Фармацевтическая Автоматическая медицинская блистерная упаковочная
- Категория: Blister Packaging Machines >>>
- Поставщик: Ruian,Antai,Pharmaceutical,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.58 $* | 0.87 $* |
| Aug-15-2025 | 0.31 $* | 0.59 $* |
| Jul-15-2025 | 0.41 $* | 0.10 $* |
| Jun-15-2025 | 0.49 $* | 0.30 $* |
| May-15-2025 | 0.77 $* | 0.14 $* |
| Apr-15-2025 | 0.48 $* | 0.69 $* |
| Mar-15-2025 | 0.86 $* | 0.2 $* |
| Feb-15-2025 | 0.79 $* | 0.1 $* |
| Jan-15-2025 | 0.14 $* | 0.93 $* |
Характеристики
Main Technical Parameters | ||
Cutting Frequency (Times/min) | 6-40 | |
Max. Forming Area and Depth(mm) | 240×150×26 | |
Stroke (mm) | 40-160 can be manufactured as user’s requirements | |
Standard Plate(mm) | 80×57 can be manufactured as user’s requirements | |
Air Pressure (Mpa) | 0.4-0.6 | |
Air supply | ≥0.3m³/min | |
Total Power | 380V/220V 50Hz 6.2kw | |
Pressure (kw) | 1.5 | |
PVC hard pieces(mm) | 0.15-0.5×250 | |
PTP Aluminum Foil(mm) | 0.02-0.035×250 | |
Dialysis Paper(mm) | 50-100g×250 | |
Mould Cooling | tap water or recycling water | |
Overall Dimensions(mm) | 2900×720×1550(L×W×H) | |
Weight (kg) | 1600 | |
Description
It is the latest generation product in our company which adopting micro-computer PLC Human interface operation, with frequency Converter, high automation, easy operation, novel figure, all-round-functions, advanced technology, stable running, durable life, qualified with GMP. It is an ideal blister packing machine for AL-plastic, paper-plastic and it has got high popularity. The products have been passed the Provincial Science and Technology Appraisal.
Features
1. The heat sealing station is fixed, the distances between forming, perforation and punching etc. Units can be adjusted freely on the same plane; it is suitable for all kinds of dimensions with high precision, strong adaptability.
2. Flat structure, registration heating, mechanic (positive pressure) forming, up and down net web, cylinder heat-sealing,
adjustable stroke, easy operation.
3. Main transmission adopts imported gear reducer, with excellent performance, lower noise, long life, stable operation.
4. Digitization and adjustable stroke, easy to operate, which suitable for different sizes packaging, especially for packing small batch but more kinds of products.
5. Photoelectric color code checking (Option), servo motor tracking traction, image and word register, which make seal formal and beautiful.
6. Equipped with photo control vibration feeder that can overcome the defects like unequal discharging by the common feeder and jammed medicine in discharging through the common feeder.
It is the latest generation product in our company which adopting micro-computer PLC Human interface operation, with frequency Converter, high automation, easy operation, novel figure, all-round-functions, advanced technology, stable running, durable life, qualified with GMP. It is an ideal blister packing machine for AL-plastic, paper-plastic and it has got high popularity. The products have been passed the Provincial Science and Technology Appraisal.
Features
1. The heat sealing station is fixed, the distances between forming, perforation and punching etc. Units can be adjusted freely on the same plane; it is suitable for all kinds of dimensions with high precision, strong adaptability.
2. Flat structure, registration heating, mechanic (positive pressure) forming, up and down net web, cylinder heat-sealing,
adjustable stroke, easy operation.
3. Main transmission adopts imported gear reducer, with excellent performance, lower noise, long life, stable operation.
4. Digitization and adjustable stroke, easy to operate, which suitable for different sizes packaging, especially for packing small batch but more kinds of products.
5. Photoelectric color code checking (Option), servo motor tracking traction, image and word register, which make seal formal and beautiful.
6. Equipped with photo control vibration feeder that can overcome the defects like unequal discharging by the common feeder and jammed medicine in discharging through the common feeder.
Q:Are you factory or a trading company？
A: We are Manufacturer of pharmaceutical machinery for more than 18 years. We provide perfect after-sale services.
Q: Can you send me the video to show how the machine works？
A: Certainly, we have many videos for reference.
Q: How can I know your machine is design for my products？
A: You can send us samples of your products and we will test it on machine.
Q: How can you ensure the machine’s quality after we put the order?
A: Before the delivery, we will send you machine’s pictures and videos, or you can come to us to have the quality checking by yourself, or by the third party inspection organization contacted by your side.
A: We are Manufacturer of pharmaceutical machinery for more than 18 years. We provide perfect after-sale services.
Q: Can you send me the video to show how the machine works？
A: Certainly, we have many videos for reference.
Q: How can I know your machine is design for my products？
A: You can send us samples of your products and we will test it on machine.
Q: How can you ensure the machine’s quality after we put the order?
A: Before the delivery, we will send you machine’s pictures and videos, or you can come to us to have the quality checking by yourself, or by the third party inspection organization contacted by your side.
