Working Principle | ||||||||
Ultrasonic quilting machines (alias: ultrasonic embossing machines, ultrasonic slitting machines, ultrasonic laminating machines, ultrasonic tweezers) are transmitted by high-frequency vibration waves to the surface of two or more materials to be welded. In the case of pressurization, the surfaces of the materials are rubbed together to form a fusion between the molecular layers, and are suitable for welding of cloth and cloth, cloth and chemical fiber cotton, plastic film and plastic film. |
Product Parameter | ||
Model No. | HC-US-1850 | |
Number of generator | 12 sets | |
Generator power | 600w*(12 sets for 1850mm width machine) can be customized | |
Working frequency | 20KHZ | |
Working speed | 100-400m/hour | |
Effective roller length | 1800MM (Customizable) | |
Motor power | 3KW+1.5KW | |
Embossed roller specification | φ136*1850mm | |
Transducer width | 153mm | |
Cooling method | Air colling | |
Weight | 3500KG | |
Dimensions | 6800*2400*1800mm (1850 type) | |
OEM Service | YES |
Features and Advantages | ||||||||
1. The welding time is short, the ultrasonic automatic suture is free of needle thread, which saves the trouble of frequent needle changing. The sewing speed is 5 to 10 times of the sewing of the sewing machine, and the width is customized by the customer; | ||||||||
2. Since the needle is not used, the stitching process is prevented from remaining in the material, and the safety hazard is eliminated, which belongs to a new generation of safety and environmental protection products; | ||||||||
3. There is no broken wire joint with traditional thread stitching, strong fixing force, clear embossing, more stereoscopic relief effect on the surface, and the product is more high-grade and beautiful; | ||||||||
4. After processing, the finished product has no pinholes and no water seepage, which is more waterproof and protective; | ||||||||
5. Using the flower roll mold, the mold change is easy, and the ever-changing and complicated discontinuous and symmetrical patterns can be stitched, and various flower-shaped patterns can be developed according to customer requirements; |
