Precision cast iron working platform



In recent years, due to some of the private enterprise to join, cast iron surface plate yields markedly increased, cast iron surface plate used in small enterprise has some changes too . Due to the development of China's industry,cast iron surface plate of expanding ceaselessly as the demand that comes from domestic market.

Maintenance

The material of surface plate is HT200-300.after your using ,pls daub rust-proof to avoid rust.





specification (mm)	precision grade (um)
	0	1	2	3	Refined Shaver
200×100	5	10	20
200×200	5	10	20
250×250	5.5	11	22
300×200	6	12	24
300×300	6	12	24
300×400	6	12	24
400×400	6	12	24
500×300	6	12	24
500×350	6	12	24
500×450	6	12	24
500×500	7	14	28
600×450	7	14	28
500×600	7	14	28
700×500	8	16	32	80
800×500	8	16	32	80
800×600	8	16	32	80
900×600	8	16	32	80
1000×750	9	18	36	90
1000×800	9	18	36	90
1000×1000	10	20	39	96
1200×800		20	39	96
1000×1200		20	39	96
1000×1500		24	48	120
1500×1500		25	50	125
2000×600		24	48	120
2000×1000		26	52	129
2000×1500			56	140
2000×2000			60	152	230
2500×1500			64	152	230
2500×2000			68	168	248
2500×2500			72	180	270



Welcome to visit our factory and make order!
