Цифровой авто краски толщина измеритель толщины пленки тестер покрытий с

Цена:120,00 $ - 200,00 $*

Количество:

Digital Auto Car Paint Thickness Meter Film Thickness Tester Coating Thickness Gauge

overview:

Coating Thickness Gauge is a highly intelligent and precise instrument used to quickly and

accurately measure thickness of coating or plating on almost all kinds of metal surface.

It not only indicates thickness of coating or plating but also automatically identifies the basematerial.

It is applicable to measure non-magnetic painting, ceramic, enamel, plastic, rubber coating on magnetic base

materials such as iron and steel , non- ferrous metal plating such as nickel & chromium, anticorrosive coating,

non- conductive painting, plastic coating and anodic oxide film on non-magnetic conductive devices .

Function:

Measuring: Continuous and Single Measurement available

Memory: 600 data store

Unit: Metric/Imperial switchable (mil/um selectable)

Backlight: Brightness adjustable, clear and easy reading under any light condition

Alarm: Set higher and lower alarm range for measuring

Calibration: Zero-in, 2 points calibration and multi-point calibration selectable

Parameter

Power supply mode	USB 5V or no.5 battery (AA)
Operation	graphic menu button operation
Man-machine interaction	keystroke, backlight dot matrix, indicator light, buzzer
Data transmission	USB,
Upper computer software	Windows upper computer, android App client, iOS App client
Application	non-magnetic coating on magnetic matrix The conductive and non-magnetic substrate with the insulation coating
Measuring range	0~1500μm
Resolution	0.1μm(0~99.9μm),1μm(100~1500μm)
Minimum surface	convex 5mm/ concave 5mm
Minimum measuring area	10 x 10mm
Thinnest base	0.4mm
Using the environment temperature	- 10-50 ℃, humidity is 10-85% RH
Measurement accuracy error	zero point calibration plus or minus (1+2%H); Multiple calibrations plus or minus (1+2%H).H represents the thickness of the coating.
