Ультразвуковой датчик уровня жидкости измерительные приборы для воды с точной

Цена:*

Количество:

Specifications

Model number	VRPWCS72
Features	Analogue signals with HART or digital signals with RS485/MODBUS are optional;
		Unique echo processing technology with the functions of an echo curve display and false echo storage;
		Built-in programmer with buttons for easy setting and calibration;
		Built-in temperature compensation; Intrinsically safe is optional.
Typical applications	For both liquid level and solid level measurement in various industrial fields, especially for water treatment industry
Measuring range	Standard probe: liquid, 0.3 - 10m; solid, 0.3 - 4m
Measuring range		Sealed and anti-corrosive probe: liquid, 0.3 - 8m; solid, 0.3 - 4m
Process connection	Thread G2''A,bracket or flange
Process temperature	-40 - +70℃
Process pressure	-0.02 - +0.1MPa
Accuracy	±0.25% of full range
Probe material	PA66+GF30/ PVDF
Ultrasonic frequency	50kHz
Explosion proof	Ex ia IIB T6 Ga
Enclosure protection grade	Plastic enclosure-IP66; AL enclosure-IP67
Signal output	4-20mA+HART, 24V DC (2-wire/ 4-wire); 220V AC (4-wire)
Signal output		RS485/MODBUS
