Бесконтактный Датчик уровня воды FRM5000 76-81 ГГц RS485 радар-трансмиттер с расстоянием 65 м для регистрации городских
- Категория: Measuring & Gauging Tools >>>
- Поставщик: Chengdu,Sentec,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 235.62 $* | 240.25 $* |
| Jul-15-2025 | 191.35 $* | 195.48 $* |
| Jun-15-2025 | 231.59 $* | 236.57 $* |
| May-15-2025 | 229.45 $* | 234.73 $* |
| Apr-15-2025 | 183.71 $* | 187.6 $* |
| Mar-15-2025 | 226.80 $* | 231.17 $* |
| Feb-15-2025 | 224.39 $* | 228.62 $* |
| Jan-15-2025 | 222.60 $* | 226.33 $* |
Характеристики
OVERVIEW
FRM5000 refers to a frequency modulated continuous wave (FMCW) radar product operating at 76-81GHz. The product range can reach 65m, and the blind zone is within 10 cm. Due to its higher operating frequency, larger bandwidth and higher measurement accuracy. The product provides the fixing method of the bracket, which makes the installation convenient and easy without on-site wiring.
FRM5000 refers to a frequency modulated continuous wave (FMCW) radar product operating at 76-81GHz. The product range can reach 65m, and the blind zone is within 10 cm. Due to its higher operating frequency, larger bandwidth and higher measurement accuracy. The product provides the fixing method of the bracket, which makes the installation convenient and easy without on-site wiring.
Transmit frequency | 76GHz~81GHz | ||
Measuring range | 0.1 m ~65m | ||
Measurement accuracy | ±1mm | Digital signal | Switch signal |
Beam angle | 6° | ||
Signal output | RS-485 | ||
Power supply | 9~36 VDC | ||
Working temperature | -40~85℃ | ||
Shell material | Stainless steel | ||
Protection class | IP67 | ||
Antenna type | lens antenna | ||
Installation method | bracket | ||
Recommended cable | 7*0.3mm² |
FEATURES
* Based on the self-developed CMOS millimeter-wave radio frequency chip, it realizes a more compact radio frequency structure, a higher signal-to-noise ratio, and a smaller dead zone.
* The 5GHz operating bandwidth enables the product to have higher measurement resolution and measurement accuracy.
* The narrowest 6° antenna beam angle, the interference in the installation environment has less inflfluence on the instrument, and the installation is more convenient.
* Integrated lens design, compact size.
* Low power consumption operation, lifespan is more than 3 years.
* When the water level exceeds the upper and lower limits (configurable), upload alarm information.
* Based on the self-developed CMOS millimeter-wave radio frequency chip, it realizes a more compact radio frequency structure, a higher signal-to-noise ratio, and a smaller dead zone.
* The 5GHz operating bandwidth enables the product to have higher measurement resolution and measurement accuracy.
* The narrowest 6° antenna beam angle, the interference in the installation environment has less inflfluence on the instrument, and the installation is more convenient.
* Integrated lens design, compact size.
* Low power consumption operation, lifespan is more than 3 years.
* When the water level exceeds the upper and lower limits (configurable), upload alarm information.
Installation Instructions
Product Application
Certifications
Packaging&Shipping
Q:What kind of products do you offer ?
A:SenTec supply pressure sensors, level sensors, temperature sensors , fiow sensors and environment sensors. Export more than 70+countries.
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q:Could I get samples?
A:Yes,we have half-stock ready products for customized sample.
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q:How about the quality of the magnets?
A:We have the certification of ISO, Europe standard ATEX, CE and ROSH ect.
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q:What is the delivery time?
A:For standard specification,delivery time 5-7days; For customized specification 10-20days.
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q: What is your terms of payment ?
A: We could accept T/T, Paypal, WU ,Trade Assurance.
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q: What is the warranty for your product ?
A: Warranty: 12-24Month, Lifetime maintenance
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q: How to contact you?
A: Email: sales01(@)cdsentec.com, Tel/wechat/whatsapp: +86 18848456685
A:SenTec supply pressure sensors, level sensors, temperature sensors , fiow sensors and environment sensors. Export more than 70+countries.
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q:Could I get samples?
A:Yes,we have half-stock ready products for customized sample.
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q:How about the quality of the magnets?
A:We have the certification of ISO, Europe standard ATEX, CE and ROSH ect.
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q:What is the delivery time?
A:For standard specification,delivery time 5-7days; For customized specification 10-20days.
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q: What is your terms of payment ?
A: We could accept T/T, Paypal, WU ,Trade Assurance.
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q: What is the warranty for your product ?
A: Warranty: 12-24Month, Lifetime maintenance
76-81GHz RS485 Non-contact 65m Level trasnmmiter Radar Water Level Sensor
Q: How to contact you?
A: Email: sales01(@)cdsentec.com, Tel/wechat/whatsapp: +86 18848456685
The specific price is subject to the parameters, please contact us for the quotation
