Milk Powder Spray Dryer Good Price Milk Powder Making Machine


Product Description


Work principle:
The air passes through the filter and the heater and enters the hot air distributor at the top of the drying chamber, and the hot air enters the drying chamber evenly in a spiral shape. The material liquid passes through the filter and is pumped to the centrifugal spray head at the top of the drying chamber, which is sprayed into very small mist-like droplets, contacting with the hot air with a large surface area, the moisture quickly evaporates in a very short time Internally dried into granular products,the wet exhaust gas is collected at the bottom of the tower and in the cyclone separator and discharged to the outdoor by the fan.

Features:
1.The drying speed is fast, and the surface area of ​​the material liquid is greatly increased by centrifugal spray. In the high-temperature air flow, 95-98% of the water can be evaporated in an instant, and the drying time is only a few seconds.
2. Suitable for heat sensitive materials. Since the droplets flow in the co-current direction with the hot air, although the temperature of the hot air is high, the material will not overheat when the water evaporates.
3. Wide range of use. A large number of materials with very different physical properties are used for production. Such as polymers and resins; dyes, pigments; ceramics, glass; rust removers, insecticides; carbohydrates; dairy products; blood and fish products; fertilizers; organic and inorganic compounds; etc.
4. The product has good dispersibility, fluidity and solubility. This is due to the fact that the drying is completed in an instant, and the product can maintain even and fine particles.
5. Simplified production process and convenient operation and control. For a solution with a moisture content of 70-90%, it can be dried into a powder product at a time. After drying, it does not need to be crushed and sieved, which reduces the production process and improves the purity of the product. For the particle size, bulk density, and moisture of the product, within a certain range, the operating conditions can be changed to adjust, and control and management are very convenient.





Main technical parameters:


Model
HL-5L
Moisture evaporation
5kg/h
Temperature
Inlet air:170-180℃
Outlet air :80-90℃
Atomizer
Speed:18000rpm
Layer diameter:50mm
Electric heating mix power
13.5kw
System heating
869634Kcal/h
Compress air
0.9m3/h
System air
1500-1800m3/h。
Atomization way
Centrifugal atomization
Feeding

Vacuum butterfly valve + cartridge
Drying system form
Open circulation system
Feeding way

Peristaltic pump steady feed
Hot air contact
Cocurrent flow
Product capture way
Cyclone 1
Heating way
Electric
Tower size
1.0(diameter)×2.2(height)m
Size
2200×1200×2200mm
Weight
0.6T
Temperature
Full pressure 76mmHg, temperature 20 ℃, relative humidity 80%
Voltage
Three phase,380V,50HZ


Detailed Images




Related Products




Packaging & Shipping


PACKAGE:

Standard export carton packing.



DELIVERY TIME:

3-20 days after confirming order,detail delivery date should be decided according to production season and order quantity.
