Высокоскоростная Центробежная распылительная сушилка Серии Lpg распылитель молочного порошка сушильная
- Категория: Spray Drying Equipment >>>
- Поставщик: Luohe,Siyu,Machinery,Co.Ltd
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 9930.73 $* | 10129.17 $* |
| Jul-16-2025 | 8054.27 $* | 8215.75 $* |
| Jun-16-2025 | 9774.77 $* | 9969.61 $* |
| May-16-2025 | 9696.92 $* | 9890.42 $* |
| Apr-16-2025 | 7741.1 $* | 7896.37 $* |
| Mar-16-2025 | 9539.67 $* | 9730.42 $* |
| Feb-16-2025 | 9461.37 $* | 9650.11 $* |
| Jan-16-2025 | 9383.95 $* | 9571.53 $* |
Характеристики
Commerical spray dryer Coffee Egg Milk Powder Making Centrifugal Spray Drying Machine
Products Description
Introduction:
Spray drying is a more widely used process in the liquid process shaping and drying industry. It is especially suitable for generating powdery and granular solid products from solutions, emulsions, suspensions and pasty liquid materials. Therefore, when the particle size distribution, residual moisture content, bulk density and particle shape of the finished product should meet the standards, spray drying is an ideal process.
Spray drying is a more widely used process in the liquid process shaping and drying industry. It is especially suitable for generating powdery and granular solid products from solutions, emulsions, suspensions and pasty liquid materials. Therefore, when the particle size distribution, residual moisture content, bulk density and particle shape of the finished product should meet the standards, spray drying is an ideal process.
Our Advantages
working principle：
The working process of this unit is that the material liquid is input through the diaphragm pump under high pressure, spraying mist-like droplets, and then descending in parallel with the hot air. Most of the powder particles are collected by the discharge port at the bottom of the tower, and the waste gas and its tiny powder are separated by the cyclone separator. , The exhaust gas is discharged by the exhaust fan, and the powder is collected by the pollinator at the lower end of the cyclone separator. The outlet of the fan can also be equipped with a secondary dust removal device.
Advantages:
1. The drying speed is fast, and the surface area of the material liquid is greatly increased after atomization. In the hot air flow, 95%-98% of the water can be evaporated instantly, and the drying time is only a few seconds, which is especially suitable for the drying of heat-sensitive materials.
2. The product has good uniformity, fluidity and solubility, high purity and good quality.
3. Simplified production process and convenient operation and control. For liquids with a moisture content of 40-60% (up to 90% for specific materials), they can be dried into powder products at one time, without crushing and screening after drying, reducing production procedures and improving product purity. The product particle size, bulk density and water content can be adjusted by changing the operating conditions within a specific range, and the control and management are very convenient.
The working process of this unit is that the material liquid is input through the diaphragm pump under high pressure, spraying mist-like droplets, and then descending in parallel with the hot air. Most of the powder particles are collected by the discharge port at the bottom of the tower, and the waste gas and its tiny powder are separated by the cyclone separator. , The exhaust gas is discharged by the exhaust fan, and the powder is collected by the pollinator at the lower end of the cyclone separator. The outlet of the fan can also be equipped with a secondary dust removal device.
Advantages:
1. The drying speed is fast, and the surface area of the material liquid is greatly increased after atomization. In the hot air flow, 95%-98% of the water can be evaporated instantly, and the drying time is only a few seconds, which is especially suitable for the drying of heat-sensitive materials.
2. The product has good uniformity, fluidity and solubility, high purity and good quality.
3. Simplified production process and convenient operation and control. For liquids with a moisture content of 40-60% (up to 90% for specific materials), they can be dried into powder products at one time, without crushing and screening after drying, reducing production procedures and improving product purity. The product particle size, bulk density and water content can be adjusted by changing the operating conditions within a specific range, and the control and management are very convenient.
Specification
Model | SY-5 | SY-25 | SY-50 | SY-150 | SY-300 | ||||
Inlet temperature (℃) | ≤250 | ||||||||
Outlet temperature(℃) | 80-90 | ||||||||
Max water evaporation (kg/h) | 5 | 25 | 50 | 150 | 300 | ||||
Transmission form of centrifugal atomizer | compressed air drive | mechanical drive | |||||||
Rotate speed(rpm) | 25000 | 22000 | 18000 | 18000 adjustable | 15000 adjustable | ||||
Atomizing disc diameter(mm) | 50 | 120 | 120 | 150 | 150 | ||||
Heat source | electric | electric | Electric+ Steam/oil/gas | Electric+ Steam/oil/gas | Equipped by user | ||||
Power(kw) | 13.5 | 31.5 | 60 | 99 | |||||
Dry powder recovery(%) | ≥95 | ||||||||
Product Display
Company Profile
Luohe siyu machinery has been a professional manufacturer and supplier for 13years.We specialize in research and development, manufacturing and sales of food machinery equipment. Our main products are including fruit and vegetable processing machinery, meat processing machinery, nut processing machinery, Bakery machinery, packaging machinery, etc. We have professional technicians and foreign trade service teams with many years of experience in the mechanical industry. We not only have first-class quality, perfect service, but also have global advanced production equipment and technology. We welcome new and old customers from home and abroad to contact us for future business relationship to achieve mutual succe.
Quality control and delivery time is strictly controlled.Reasonable price: We are factory and able to offer better price.Fast reply: All your enquiry will be replied within 12 hours.Good quality: We are OEM suppliers.
Quality control and delivery time is strictly controlled.Reasonable price: We are factory and able to offer better price.Fast reply: All your enquiry will be replied within 12 hours.Good quality: We are OEM suppliers.
Packing & Delivery
PACKING
Standard export wooden case packing, fit for multiple handing and long distance air/ marine shipping.
DELIVERY TIME
For stock type, we can send within 48hrs after confirming order.
For customized type , delivery date need to be negotiated before taking order.
Standard export wooden case packing, fit for multiple handing and long distance air/ marine shipping.
DELIVERY TIME
For stock type, we can send within 48hrs after confirming order.
For customized type , delivery date need to be negotiated before taking order.
FAQ
Question 1: What are your advantages compared with your competitors?
Answer:
With rich industry experience and strict Product Quality Control systems, we provide:
1). Stable and reliable product at reasonable price
2). Good customer service: Fast response to any inquiry or question
3). On-time delivery.
Question 2: Are you manufacturer?
Answer: Yes, we are manufacturer with more than 10 years' experience.
Question 3: What are your Price Terms?
Answer: Price can be based on FOB, CFR, or CIF, etc.
Question 4: What are your Payment Terms?
Answer: Payment shall be made by T/T, L/C, or D/P, etc., it varies considerably according to the region that you are in.
uestion 5: What's your Minimum Order Quantity?
Answer: Any order quantity is warmly welcomed.
Question 6: Do you have English Manual for each machinery?
Answer: Yes. The instruction manual,the test report and other Data Sheets related shall be provided by us.
Question 7: Can I print my Logo on the machine?
Answer: Yes, sure.
Answer:
With rich industry experience and strict Product Quality Control systems, we provide:
1). Stable and reliable product at reasonable price
2). Good customer service: Fast response to any inquiry or question
3). On-time delivery.
Question 2: Are you manufacturer?
Answer: Yes, we are manufacturer with more than 10 years' experience.
Question 3: What are your Price Terms?
Answer: Price can be based on FOB, CFR, or CIF, etc.
Question 4: What are your Payment Terms?
Answer: Payment shall be made by T/T, L/C, or D/P, etc., it varies considerably according to the region that you are in.
uestion 5: What's your Minimum Order Quantity?
Answer: Any order quantity is warmly welcomed.
Question 6: Do you have English Manual for each machinery?
Answer: Yes. The instruction manual,the test report and other Data Sheets related shall be provided by us.
Question 7: Can I print my Logo on the machine?
Answer: Yes, sure.
