Высокоскоростная Центробежная распылительная сушилка для сухого молока сушильная машина высокого качества LPG-100
- Категория: Spray Drying Equipment >>>
- Поставщик: Henan,Workers,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 71162.37 $* | 74720.75 $* |
| Aug-17-2025 | 70564.11 $* | 74092.64 $* |
| Jul-17-2025 | 59202.78 $* | 62162.59 $* |
| Jun-17-2025 | 69368.83 $* | 72836.78 $* |
| May-17-2025 | 60398.76 $* | 63418.54 $* |
| Apr-17-2025 | 68172.3 $* | 71581.67 $* |
| Mar-17-2025 | 67574.97 $* | 70953.36 $* |
| Feb-17-2025 | 66976.90 $* | 70325.83 $* |
| Jan-17-2025 | 66378.33 $* | 69697.61 $* |
Характеристики
Industrial centrifugal spray dryer
The spray dryer is one of the continuous atmospheric dryers. The liquid material is sprayed with a special device to form a mist and is dried in contact with hot air. For the drying of some heat-sensitive liquids, suspensions, and viscous liquids, such as milk, eggs, tannins, and drugs. Also used for drying fuels, intermediates, soap powder, and inorganic salts.
High-speed drying: the surface area of liquid material is greatly increased after atomization, achieving instantaneous evaporation of 95% -98% water in the hot air flow, drying time only takes a few seconds, especially for heat-sensitive materials.
Products achieve good uniformity, mobility, and solubility, and also achieve purity, good quality. The production process is simplified and the operation control is convenient. For liquid materials with the moisture content of 40-60% (special materials up to 90%) can be dried into powder products just with one time, do not need grinding and screening after drying, reduce production processes and improve product purity. The product size, bulk density, moisture, in a certain range can be adjusted by changing operating conditions, control and management are very convenient.
Atomizer
Observation window
Control box
PLC touch screen control panel
Push button control panel
Working Principle
The air is filtered and heated into the top of the dryer air distributor, hot air into the spiral evenly into the drying chamber.
The material liquid is sprayed into a finely atomized liquid droplet through the high-speed centrifugal nebulizer at the top of
the tower body, and can be contacted with the hot air in a very short time and can be dried into finished products. The finished product is continuously discharged from the bottom of the drying tower and the cyclone, and the exhaust gas is drained by the draft fan.
The material liquid is sprayed into a finely atomized liquid droplet through the high-speed centrifugal nebulizer at the top of
the tower body, and can be contacted with the hot air in a very short time and can be dried into finished products. The finished product is continuously discharged from the bottom of the drying tower and the cyclone, and the exhaust gas is drained by the draft fan.
Technical parameters
Item丨Model | LPG-5 | LPG-25 | LPG-50 | LPG-150 | LPG-200~2000 | |||||
Inlet temp. ℃ | 140~350 | 140~350 | 140~350 | 140~350 | 140~350 | |||||
Outlet temp. ℃ | 80~90 | 80~90 | 80~90 | 80~90 | 80~90 | |||||
Max. water evaporation kg/h | 5 | 25 | 50 | 150 | 200~2000 | |||||
Transmission form of centrifugal atomizer | Compressed air transmission | Mechanical transmission | Mechanical transmission | Mechanical transmission | Mechanical transmission | |||||
Maximum speed (r.p.m) | 25000 | 18000 | 18000 | 15000 | 8000-15000 | |||||
Diameter of atomizer (mm) | 50 | 120 | 120 | 150 | 180-240 | |||||
Heat source | Electricity | Electricity, steam, natural gas, LPG | ||||||||
Max. power of electric heater (kw) | 9 | 36 | 72 | 99 | ||||||
Overall dimensions (LWH) (m) | 1.8*0.93*2.2 | 3*2.7*4.26 | 3.5*3.5*4.8 | 5.5*4*7 | ||||||
Dry powder recovery rate (%) | ≥95% | |||||||||
Note: The amount of water evaporation is related to the characteristics of the material and the temperature of the hot inlet and outlet. | ||||||||||
Information provided by the user
◎Name of material and liquid, physical properties: solid content (or water content), viscosity, surface tension, PH value.
◎After drying, powder capacity, allowable residual water content, particle size and allowable maximum temperature.
◎Production, daily working hours.
◎Available energy: steam pressure available, electric capacity, available for coal, oil and gas.
◎Control requirements: Whether the inlet and outlet temperatures need to be controlled automatically.
◎Powder collection requirements: whether to install bag traps, and environmental requirements for exhaust emissions.
◎Other special requirements.
◎After drying, powder capacity, allowable residual water content, particle size and allowable maximum temperature.
◎Production, daily working hours.
◎Available energy: steam pressure available, electric capacity, available for coal, oil and gas.
◎Control requirements: Whether the inlet and outlet temperatures need to be controlled automatically.
◎Powder collection requirements: whether to install bag traps, and environmental requirements for exhaust emissions.
◎Other special requirements.
Lab scale model
