Цифровой ультразвуковой

Категория: Измерительные инструменты >>>
Поставщик: Zibo,Senyuan,Electric,Co.,Ltd.

Цена:110,00 $ - 130,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-17-2025	131.82 $*	138.44 $*
Aug-17-2025	130.41 $*	137.13 $*
Jul-17-2025	109.99 $*	114.44 $*
Jun-17-2025	128.84 $*	134.11 $*
May-17-2025	111.45 $*	117.77 $*
Apr-17-2025	125.66 $*	131.43 $*
Mar-17-2025	124.37 $*	130.52 $*
Feb-17-2025	123.12 $*	129.89 $*
Jan-17-2025	122.34 $*	128.36 $*

Характеристики

Recommend Products

Products Display

Product Description

Ultrasonic thickness gauge is a kind of high-precision thickness gauge which uses ultrasonic measurement principle, adopts high-speed processor and high integrated chip design to realize portable, nondestructive, fast and accurate measurement of thickness and sound velocity of various materials. It is suitable for measuring the thickness of various materials, such as steel, metal, glass, ABS, plastics, PVC, ductile iron, etc., which can be transmitted by ultrasonic wave at a constant speed in its back.

Main Feature

It is suitable for thickness measurement of various materials: various metals, glass, plastics and other materials;
The instrument is exquisite and compact, with 2.3-inch color screen display, which is easy to carry, Suitable for on-site inspection
Measurement mode: standard mode / ultra-thin mode (for High-precision large range type)
Measurement mode: standard mode / Penetration coating mode (special for penetrating type)
High measurement accuracy, wide measurement range, single probe full range
Chinese and English bilingual version
Bluetooth interconnection data transmission function (applicable to Bluetooth thickness gauge)
Calibration: standard block calibration, sound velocity calibration, sound velocity can be calculated by known thickness
Two kinds of manual shutdown and automatic shutdown, users can choose at will;
Built in sound speed of 7 kinds of commonly used materials, which can be edited and convenient for users to use;
Humanized data storage mode: mass storage, and can save data in groups, can store 10 groups of data, each group can save 200 data, and can store 2000 data
Large capacity storage, view, delete operation, convenient and simple
Multi probe selection use, high temperature environment measurement can be equipped with high temperature probe, high temperature resistance (300 ℃)

Technical Data

Model	SYT100
Measuring Range	0.9-300mm(5P,φ10)
Display Resolution	0.1mm
Measurement Resolution	±（0.1+1%H）mm
Material Velocity	1000～9999m/s
Bandwidth	1MHz～10MHz(-3dB)
Power Supply	4.5VDC (three AAA batteries)
Screen	TFT Color screen 2.3 inch
Size	130（L）×70（W）×25（H）mm
Weight	125g (excluding batteries)
Material Velocity	1000～9999m/s
Bandwidth	1MHz～10MHz(-3dB)
Power Supply	4.5VDC (three AAA batteries)
Screen	TFT Color screen 2.3 inch
Size	130（L）×70（W）×25（H）mm
Weight	125g (excluding batteries)

Standard Delivery

NO	Item name	Quantity
1	Thickness gauge	One
2	Standard probe (5P, φ 10)	One
3	Coupling agent (50ml)	One
4	Battery	Three AAA batteries
5	Manual	One
6	Qualification certificate	One
7	Instrument package	One
