Металлический микро фрезерный сверлильный станок с переменной скоростью


Поделиться:


Цена:*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-15-2025 0.48 $* 0.39 $*
Aug-15-2025 0.98 $* 0.26 $*
Jul-15-2025 0.98 $* 0.51 $*
Jun-15-2025 0.21 $* 0.40 $*
May-15-2025 0.14 $* 0.60 $*
Apr-15-2025 0.48 $* 0.91 $*
Mar-15-2025 0.32 $* 0.1 $*
Feb-15-2025 0.66 $* 0.16 $*
Jan-15-2025 0.99 $* 0.22 $*

Характеристики



Product Description


Specification
Model No
KY400
Distance between centers
400mm
Swing over bed
420mm
Taper of spind bore
MT3
Spindle bore
20mm
Range of spindle speeds
160-1360rpm
Range of lingitudinal feed
0.05-1.75mm/r
Range of inch threads
8-120T.P.I
Tange of metric threads
0.2-3mm
Travel of top slide
80mm
Travel of cross slide
120mm
Tailstock spindle travel
70mm
Taper of tailstock quill
MT3


Drilling &Milling
Drill capacity
15mm
Milling table
150*200mm
End mill capacity
20mm
Face mill capacity
63mm
Spindle travel
85mm
Taper in spindle bore
M.T.3
Range of spindle speeds
117 ~1300RPM


Standard Accessories
Drilling chuck
1 pc
Toolbox & tools
1 set


Optional accessories
Four-jaw chuck
1 set
Backplate
1 pc
Follow rest
1 pc
Steady rest
1 pc
Face plate
1 pc
Collet chuck
1 set
Turning tools
1 pc


Features

1.360°  rotation in vertical plane
2.Drill / Mill vice-incorporated in top slide
3.Power lingitudinal feed allows threading
4.Forward / Reverse switch
5.Magnetic switch and chuck cover according to "CE" standard
6.Fully-adjustable carriage

7.Four-Position Turret Post
8.Shielded and lubricated-for-life bearings






Packing & Delivery








Warehouse to film




Related Products





    KY500/KY800









             KY450A/KY700A




Our Company


Since establishing, after years of effort, we, which is Kaiyun Machinery have grown into a professional supplier of Metalworking and woodworking machinery in China, with more than 50 domestic qualified factories as our long-term and OEM partners. Outstanding technical engineers & strict inspector ensure us turn out high quality products because they all know this is the absolutely vital that the quality is the basic of products. Our all products are exported to the worldwide markets, especially in America and Europe market.








Our Service


You can enjoy the best after service when you purchase our any product. Our technician take serious to the every quality information feedback of our products each time, and would reply it as soon as possible. We will keep trying our best to guarantee your satisfaction, and to assure the product we send to you will meet the high quality and durable standards. If you are interested in our products or have special requirements, pls feel free to contact us without delay. Then we, Sale Dept will give you a satisfying reply within 24 hours!
