RCGF 3-in-1 black tea,coffee soy milk automatic beverage filling production line

Equipment description:

1.The equipment is used in production of noon-soda drink of fruit juice,fruit wine,minerals and pure water packed in polyester bottles.

2.Washing,filling and capping are integrated in one machine.

3.The whole machine is controlled by PLC with touch-screen as the human-machine interface.

4.The amout of the drinks in the storage tank can be controlled automatically.

5.The filling and capping will be stopped automatically when bottles are cramped wrongly or when caps are not available,the machine can automatically.

6.The frequency changing technology is used to adjust the operation speed steplessly.

7.The production can be displayed digitally and can be adjusted conveniently.



Equipment technical parameters:

Model	RCGF1612126	RCGF1818186	RCGF2424248	RCGF32323212	RCGF40404015	RCGF50505018	RCGF60606020
Head of washing, filling, sealing	16-12-12-6	18-18-186	24-24-248	32-32-32-12	40-40-40-15	50-50-50-18	60-60-60-20
Production capacity (bottle/hour)	4000-5000	6000-8000	8000-10000	10000-12000	12000-14000	15000-16000	18000-20000
Suitable bottle diameter(mm)	φ=50-90 H=150-310 330-1500ml	φ=50-90 H=150-310 330-1500ml	φ=50-90 H=150-310 330-1500ml	φ=50-90 H=150-310 330-1500ml	φ=50-90 H=150-310 330-1500ml	φ=50-90 H=150-310 330-1500ml	φ=50-90  H=150-310  330-1500ml
Spraying pressure	0.25	0.25	0.25	0.25	0.25	0.25	0.25
Motor power	3.13kw	3.84kw	4.1kw	5.6kw	7.5kw	9kw	11kw
Power of outer vacuum pump	0.3-0.7	0.3-0.7	0.3-0.7	0.3-0.7	0.3-0.7	0.3-0.7	0.3-0.7
Overall dimension    (mm)	2100×1650×2300	2400×1900×2300	2800×2100×2300	4200×2300×2300	5000×2800×2400	5900×3100×2400	6500×3500×2400
Weight(Kg)	2500	3000	4000	5000	7500	9000	11000
