480V 540V 600V DC Lithium Battery bank Charge controller from PV modules (PWM or MPPT type)

Product Characteristic for 480V 540V 600V DC Lithium Battery bank Charge controller from PV modules (PWM or MPPT type)

1. The solar charger controller adopts industrial-grade chips to ensure the stable feature of controller


2. Excellent EMC design


3. High efficient PWM charging technology which has three charging stages (buck charging stage, equalize charging stage and float charging stage), and improves battery storage efficiency and charging efficiency.


4. Advanced battery activation technology which increases battery lifetime 30% at least and improves the system performance


5. The solar charger controller adopts imported IGBT power module or MOSFET as electronic switch which can improve the stable performance of controller. There aren’t any mechanical switches in the system


6. LCD will display the system status and working parameters


7. Parameters setting flexibly


8. Users can parallel connect lots of the controller is a system


9. Fully enclosed duct design and high speed fan for cooling making the controller working in a variety of harsh environments


10. DC output function (Optional)


11. Standard Modbus protocol for RS-485 communication to extend the communication distance (Optional)


12. The solar charger controller will alarm when the system status is abnormal


13. New SOC method displays battery power accurately


14. With power generation statistics function to facilitate the view of power generation of daily, month and total


15. There is temperature compensation function which will compensate the temperature according to different battery type


16. The solar charger controller adopts graphical dot-matrix LCD and 4 buttons as HMI for full menu and easy operation


17. RTC time function

 Parameters of 480V 540V 600V DC Lithium Battery bank Charge controller from PV modules (PWM or MPPT type)

System voltage BZC-	24V	48V	96V	192V	240V	360V	480V	540V	600V
Max. VOC of PV arrays	100V	100V	200V	350V	450V	700V	950V	1000V	1000V
Rated charging current	√150A             √200A             √250A             √300A             √350A             √400A
Equalize charging point	28.8V	57.6V	115.2V	230.4V	288V	432V	576V	648V	720V
Equalize charging recovery point	26.4V	52.8V	105.6V	211.2V	264V	396V	528V	594V	660V
Equalize charging time	120 minutes (default setting)
Float charging point	27.6V	55.2V	110.4V	220.8V	276V	414V	552V	621V	590V
Over voltage point	32V	64V	128V	256V	320V	480V	640V	720V	800V
Over voltage recovery point	30V	60V	120V	240V	300V	450V	600V	675V	750V
Standy-by consumption	<0.5W
Display	3'' LCD
Display language	English
Terminal typy	TC series barrier terminal
Elevation	<4000 meter, should reduce power if the elevation high than 4000 meter
Humidity	0~98%, non-condesing
Protection level	IP32
Noise	<30dBA
Cooling method	High speed fan + heat sink
Environment temperature	-25°c~55°c
Dimension	900*520*500mm
Net Weight	75KG

 Above parameter only for reference ,could be custom made to user specifications



MPPT type pv charge controller optional:







Q1. What's the payment term?

A. We accept TT,Western Union,Paypal,MoneyGram.



Q 2.How's the delivery time ?

A. Is due to order quantity, usually it will take about 3-7days for sample production,

Q 3.Tell me the standard of package?

A. For the small capacity, it use carton, but for big capacity, we should use honeycomb carton and pallet or  wooden case for protection.



Q 4.Would you accept to use our logo ?

A.It's no problem to do OEM.

Q 5.We want to know month capacity.

A. It depends on which model.For example for relay type small capacity , month capacity can reach near 2000pcs  and big capacity near 500pcs.

Q 6.Where is your market?

A. Our products are popular in Australia,South America,Philippines,Italy, America, Pakistan and so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutural benifit from our cooperation.

Q 7. What kind of certificate you have ?

A. Our company already achieve ISO9001, and for products, we have CE, SAA, G83 G59 etc .



Q8. What is the warranty period ?

A. Normally 1 year .



OEM Services
1.Logo
Please offer us your own high resolution logo in JPG format,there should be two colors at most in the logo and there should be no gradient effect in the logo.
2.Label
Please offer us your own model numbers.
3. Manual
Please offer us the finished manual file that can be printed directly.



Lead Time
1.Sample orders will be delivered from our factory within 3-7 working days.

2.General orders will be delivered from our factory within 15-30working days.
3.Big orders will be delivered from our factory within 45 working days at most



Shipment
1.By EMS,DHL,FedEx,TNT,UPS or other express.

2.By our forwarding agent(by air or by sea).

3.By your own forwarding agent.
4.By domestic forwarding agents to any city in China.
