Автоматическое моторное масло с сервоприводом машина для розлива и
- Категория: Разливочные машины >>>
- Поставщик: Zhangjiagang,Mic,Machinery,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 29750.55 $* | 31238.36 $* |
| Aug-19-2025 | 29500.20 $* | 30975.67 $* |
| Jul-19-2025 | 24750.95 $* | 25988.95 $* |
| Jun-19-2025 | 29000.78 $* | 30450.23 $* |
| May-19-2025 | 25250.22 $* | 26513.80 $* |
| Apr-19-2025 | 28500.61 $* | 29925.85 $* |
| Mar-19-2025 | 28250.90 $* | 29663.54 $* |
| Feb-19-2025 | 28000.56 $* | 29400.15 $* |
| Jan-19-2025 | 27750.94 $* | 29138.36 $* |
Характеристики
Product Introduction
Introduction of machine:
The equipment is mainly used for pesticide, chemical, water agent kind of liquid bottles, packaging, can be applied to a variety of different types of containers. It can form a production line with capping machine and labeling machine. The adoption of high quality components ensures excellent quality and long - lasting and stable performance. Material cylinder and three-way valve adopt handcuffed quick connection, No need any tools, Easy Disassembly, So maintenance and cleaning is very convenient. Photoelectric counter, PLC controlling, Truly do no bottle no filling, Filling accurately. The anti-drip filling system can effectively prevent the occurrence of drip and wiredrawing.
Main features
* Servo motor control Double screw rod and filling heads lifting and dive , ensure machine running stable.
* Piston pump cylinder control filling, ensure filling accuracy
* Anti-drop filling head. Can filling high vicosity material.
* Machine tank and machine frame use Stain steel 316/304 material
* Can connect with capping machine, labeling machine combine to a production line
Equipment Parameter
Parameter | MIC-ZF4 | MIC-ZF8 | MIC-ZF12 | MIC-ZF16 | MIC-ZF20 | ||||
Application | Engine oil, grease oil, lubricating oil, motor oil, edible oil, cooking oil, olive oil, detergent, tomato sauce, ketchup, honey, viscoaity liquid and so on. | ||||||||
Packing Type | Cans,Plastic bottles, glass bottles, barrels, drums, pails, etc | ||||||||
Capacity | 500-800BPH | 1000-2500BPH | 2000-3000BPH | 3000-4000BPH | 5000-6000BPH | ||||
Filling Range | 100ml,250ml,500ml,1L, 2L, 3L,5L and so on(0.1-5L) | ||||||||
Power | 1.5KW | 2KW | 3KW | 3.5KW | 4KW | ||||
Product Advantage
Piston Cylinder
Brand: MIC
Original: China
According to customer's need filling volume, customize the volume of piston cylinder. The piston moves up and down in the cylinder, which is converted into rotary motion by the piston connecting rod and crankshaft.
It suitable for high viscosity liquid.
Filling Head
Brand: MIC
Original: China
Especially design anti-leak filling head, Piston pump control filling head, ensure the filling volume accuracy. The height of filling head can be adjusted through the adjust handle, the filling head can suitable different height and volume bottles. Filling volume can adjust according to customer's reuqirments. No bottle no filling.
Material Tank
Brand: MIC
Original: China
1.The Liquid tank is made of 316 stainless steel, corrosion resistance.
2.The ball valve is made of quality of 316 stainless steel to keep long using life.
3.The material tank design with the slope design, to facilitate the customer to clean the tank easily, conforms to the GMP request.
Solenoid Valve
Brand: MIC
Original: China
The solenoid valve is used to exclude the pulse of the servo motor and used to avoid the fluid goes back, in order to achieve better filling precision.
Servo Motor
Brand: MIC
Adopt servo motor drive, double screw-rod drive, Control the movement of the piston rod to ensure the stability of the filling.
The servo motor can transmit more than 10000 pulses with one revolution, and the pulse collected from the servo motor knows that the filling amount has reached the set requirement. In order to assure the filling accuracy.
Detailed Image
Why Choose Mic
Mic Machinery Co., Ltd. MIC is a professional manufacturer and supplier of daily use chemical and drink machine in China.
We have a well-experienced team to manufacture pharmaceutical machinery and equipments and a professional design institute. With rich experiences in pharmaceutical machinery and equipment field and numbers of professional engineers, we have designed and developed many types of machinery and equipments including soft tube filling sealing machine, aluminum tube filling sealing machine, homogenizer mixer, dryers, water chiller, capsule filling machines, PE film packing machine, inkjet printer machine etc.
Due to our good credit and service, we have made great achievements in the past years. We have established long-term business relations with many customers and some of our overseas customers have appointed us to be their purchase agency in China. Our products are exported to many countries & areas, such as Korea, India, Indonesia, Pakistan, Thailand, Vietnam, Japan, Denmark, Romania, Bulgaria, Russia, South Africa, Nigeria, the USA, Australia, Canada, Argentina and Chile. Besides machinery and equipment, we also supply production lines.
In MIC machinery you can get your desired goods with the best price and good quality. Welcome your enquiries from all over the world.
Certifications
Packing & Delivery
Packaging and shipping
1. Before packaged& delivered, we will test the machine seriously and guarantee the machine runs stably with high accuracy.
2. After inspection, our machines are wrapped by plastic film and then carefully packed in wooden cases.
3. Sea transportation can be provided by us.
Micmachinery Servo Motor Engine Oil Can Filling Seaming Machine for Lubricating Oil Canning Line Equipment
FAQ
Q1: Are you a Manufacturer or Trading company?
A1: We are the manufacturer from Jiang su,so we can offer the best quality and price of the machine to you.
Q2: How can I install CCG1000-20B Automatic Piston Filling Machine Line when it arrives?
A2:We will send the instruction book and some videos to you to help you install the machine.You can talk with our engineer by video chat or we will send the engineers overseas to help you.
Q3: What is the cost to send installation/training staff? How many staff do you need to send?
A3: Whole installation/traning process needs 2peoples. Around 10days. Client needs to provide us round-air ticket, visa fee, local transpotation, accomodation, food, and 100USD/day/person.
Q4: Do you offer a free set of replacement parts for parts that commonly wear out quickly?
A4: All spare parts are always avaliable for delivery. Above 90% spare parts are made by ourselves. Because we have our own processing center, so we can supply at anytime.
Q5: Beside Piston filling Machine, can you supply other accessories like cap sealing machine or labeling machine for complete line?
A5: Yes we are a professional factory that can provide turnkey solution. Just free to send us inquiry is ok
Micmachinery Servo Motor Engine Oil Can Filling Seaming Machine for Lubricating Oil Canning Line Equipment
