Индивидуальные оцинкованный горячим способом в виде СИД стадиона уличный фонарный
- Категория: Фонарные столбы >>>
- Поставщик: Yixing,Huayuan,Lighting,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 595.69 $* | 625.51 $* |
| Aug-17-2025 | 590.78 $* | 620.36 $* |
| Jul-17-2025 | 495.18 $* | 520.13 $* |
| Jun-17-2025 | 580.85 $* | 609.7 $* |
| May-17-2025 | 505.68 $* | 530.79 $* |
| Apr-17-2025 | 570.93 $* | 599.68 $* |
| Mar-17-2025 | 565.29 $* | 593.3 $* |
| Feb-17-2025 | 560.59 $* | 588.37 $* |
| Jan-17-2025 | 555.18 $* | 583.50 $* |
Характеристики
Product Description
SPECIFICATION | ||
Material | Hot rolled steel, Q235,Q345,S235,S355,SS400,Gr 50 | |
Yield Strength Of Material | Minimum yield strength>=235n/mm2 for Q235, S235 and SS400 Minimum yield strength>=345n/mm2 for Q345 S355 and Gr 50 | |
Height | 3m –30m | |
Length Of One Part | Within 16m once forming without slip joint | |
Wall Thickness | 2.3mm-30mm | |
Pole Shape | Round, Polygonal, Taper Octagonal, Taper round, Round conical, Taper Square, Square | |
Arm Type | Single arm, Double arm, Tri-arm, Four-arm | |
Power | 150W to 400W | |
Welding | Advanced submerge-arc welding and CNC welding equipment; Welding standard : international welding standard of EN1090 and AWS D 1.1; | |
Galvanization | Hot dip galvanization with thickness of 80-100µm average can meet requirment of ENBS1461 or Chinese standardGB/T 13912-2002 or American standard ASTM A123, ISO: 2626-1985 | |
Wall Thickness Tolerance | ±0.1mm from 2.3mm to 4mm ±0.2mm from 5mm to 20mm ±0.5mm from 22mm to 30mm | |
Painting Color | RAL Color Chart(customerized) | |
Surface Treatment-1 | Black pole, Rough pole | |
Surface Treatment-2 | Hot dip Galvanizing antirust | |
Surface Treatment-3 | Hot dip galvanizing with powder coating | |
Temperature Range | -25 °C~+45 °C | |
Wind Speed | Aganist wind pressure of 120Km/h to 180Km/h;According to design requirements | |
Base Plate Mounted | Square, octagonal or round in shape with slotted holes for anchor bolt (customized) | |
Ground Mounted | Buried underground length according to customer's requirements. | |
Certifications
ISO9001 | ISO14001 | OHSAS18001 | CE Certificate |
Production Process And Quality Control
Quality control through whole production process
Why Choose Yixing Huayuan Lighting
Founded in 2001,Yixing Huayuan Lighting is one of the earliest lighting industry companies in China. After several years working unceasingly, our company manufactures various lighting steel poles,traffic facilities, street light poles, lamp poles ,transportation signal rods, monitor poles,outdoor illuminations, power transformer steel poles,communication tower poles,cable poles, advertisement poles,billboard poles and wind power generation seats.
All products are customized, so please feel free to send me inquiry.
All products are customized, so please feel free to send me inquiry.
