 Top quality paper box sample cutting machine











 DCH10(1)





DCH10(2)














Detail





DCH10 series card paper box cutting machine is mainly for the card paper and thin plastic box cutting application. It good used in the thin and homogenous material. Its very capable for the low cost sample making, although the cutting material is homogenous, it has the bright point for the specify material. This machine can cut and crease the materials of card paper, plastic film board etc, by the tool pen, creasing tool and special knife it comes with. Moreover, this machine can be used to as die cutting drawing.
The main features
·Equips with the pen, creasing tool, special knife
·Steel belt driven system, accuracy assured.
·Beautiful appearance by mould cover
·Easy to move with the universal wheel








Specification




































































































Model



DCH100906



DCH101209



DCH101512



Effective cutting area



900*600mm



1200*900mm



1500*1200mm



Driver



Step motor



Configuration



Pen, special knife, creasing tool



Way of fixing paper way



Vacuum absorbing



Driving material



Import steel belt



Cut materials



Red hard paper,plastic board,white board,kraft paper,thin PVC



Cutting way



Drawing by pen,half cutting,whole cutting



Cutting thickness



0.5-2mm



Cutting precision



≤0.1mm



Max speed



1000mm/s



Working time and character



Continuous work, operating computer and cutting at the same time, linear high-speed transmission for data.



Transmitting port



International standards: parallel port/RSC232 serial port



Capacity of buffer area



Buffer area of large capacity, it can finish high-speed transmission for data at a time



Instruction set



International standards: HP-GL or DXF format can be selected, F



Numerical control board



LTD, all-English operating menu



Main structure



Cutting platform,head,driving system,control cabinet,control micro computer,frame,vacuum pump



Voltage



AC 220V±10% 50Hz



Fuse standard



5A



Occupy dimension(L*W*H)



1335*1065*1080mm



1635*1365*1080mm



1935*1665*1080mm



Note



Other size can be customized.







 WoWorking sample





12






Company Information











Certifications








Customers











Our Services





Training and Use

1. We will supply with the machine operation manual in English version for installing and operation.


2.Customer can come to our factory training .

3.Our engineer can go to customer's factory training.


Warranty and After service


1. Our warranty is 2 years counting from the date when the Machine arrives at the port of

destination.

2. We will supply after service 24 hours,customer can contact us any time.

3.When some problems can’t be solved by customers, our engineer can go to door to help.








FAQ


 Questions and answer:

Q1.how to get the most suitable machine and best price

Please tell the material and thickness you want to cut?


What’s the MAX size of these material ?( length ? Width ? Thickness ?)

Q2.What is the payment?

The payment is 30% or 50% T/T or Alibaba trade assurance in advance, balance after machine finished.

Q3.What is the producing time after order?

The proucing time is about 10-20 days depend on different machines.

Q4.If we don't know how to use the machine,can you teach us?

Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if

you are busy ,we will have the special engineer to your country,but you need to bear some fee,like

tickets and hotel and meal.

Q5.How about your after-sales service?

we offer you 24 hours service phone,skype or whatsapp, our engineer also can go to door install or training.

Q6. Quality Control:

The whole production procedure will be under regular inspection and strict quality control. The

complete machine will be tested to make sure they can work very well before being out of factory.

The testing video and pictures will be available before delivery.
