Power Over Ethernet POE разделитель адаптер с скорость передачи данных до 10/100 Мбит/с и DC12V 2A выходная
- Категория: Ethernet & Communication Modules >>>
- Поставщик: Shenzhen,Caratar,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 2.47 $* | 2.71 $* |
| Aug-18-2025 | 2.28 $* | 2.50 $* |
| Jul-18-2025 | 2.60 $* | 2.28 $* |
| Jun-18-2025 | 2.11 $* | 2.23 $* |
| May-18-2025 | 2.93 $* | 2.93 $* |
| Apr-18-2025 | 2.28 $* | 2.21 $* |
| Mar-18-2025 | 2.30 $* | 2.9 $* |
| Feb-18-2025 | 2.49 $* | 2.7 $* |
| Jan-18-2025 | 2.98 $* | 2.44 $* |
Характеристики
Supply power and transfer data via a single Ethernet cable remotely to non-PoE devices like some IP cameras, wireless access points and VoIP phones which need 12V DC input in a 2.1mm x 5.5mm barrel jack
Product Description
Output :12v series
Description
This item is a Power Over Ethernet POE Splitter POE Adapter, which has a date transfer rate of 10/100Mbps and DC12V1A- 2A power output, suitable for monitor transmission and power supply.
Features
- Output Power: 12V/1A-2A, 15.4W, full IEEE 802.3af compliant.
- Input Power Voltage: DC 44-57V standard POE switches, overvoltage protection.
- Data Rate: 100/100Mbps; DC Jack: 5.5*2.1mm.
- Plug and play, no configuration required.
- Package content: 2 x PoE splitters
| Voltage | Popular V | Current | Work Amp | Overload Amp | Non-Loading Amp |
| 44-57V | 48V | 500-550mA | 10-350mA | 350-500mA | Max 5mA |
| Mark: PD device ask 3.84-12.95W , Max 13W | |||||
More PoE product customized requirement, freely contact on line sales or by mail: sales @ caratar.com
Product Application
Application
1.HD monitor transmission and power supply.
2.Wireless AP layout transmission and power supply.
3.Network telephone transmission , intelligent house and home system.
4.Intelligent transportation supervisory system.
5.High-speed Way supervisory/Tele-Communication System.
6.Security protection system, TV medical treatment.
7.Long-distance Muti-media Schooling, Campus monitoring.
8.Long-distance broadcast television transmission system.
9.High-building Security Protection, Military Tele-Com projects.
10.Complies with IEEE 802.3af Power over Ethernet.
11.Splits the 48V DC power over RJ-45 Ethernet cable into different DC output.
12.Data and power transmission distance up to 160 meters.
13.Auto-Detect of IEEE 802.3af PoE equipment.
