Bwitt Лучшая цена Гибридный MPPT солнечный инвертор 3 кВт сетка с одной фазой на решетки для солнечной системы
- Категория: Контроллеры солнечных зарядных устройств >>>
- Поставщик: Shenzhen,Bwitt,Power,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 0.39 $* | 0.24 $* |
| Aug-15-2025 | 0.62 $* | 0.47 $* |
| Jul-15-2025 | 0.63 $* | 0.94 $* |
| Jun-15-2025 | 0.21 $* | 0.44 $* |
| May-15-2025 | 0.34 $* | 0.69 $* |
| Apr-15-2025 | 0.17 $* | 0.83 $* |
| Mar-15-2025 | 0.87 $* | 0.75 $* |
| Feb-15-2025 | 0.71 $* | 0.37 $* |
| Jan-15-2025 | 0.21 $* | 0.27 $* |
Характеристики
Product Description
Bwitt Best Price Hybrid MPPT solar inverter 3KW
Product Parameter
MODEL | SCH-60A | SCH-70A | SCH-80A | SCH-90A | SCH-100A | ||||
Solar system voltage | 12V/24V/36V/48V Auto work | ||||||||
PV Operating Voltage | 18~150Vdc@12V 35~150Vdc@24V 50~150Vdc@36V 60~150Vdc@48V | ||||||||
Max. PV Input Power | 12V 900W | 12V 1000W | 12V 1200W | 12V 1300W | 12V 1400W | ||||
24V 1800W | 24V 2000W | 24V 2300W | 24V 2600W | 24V 2800W | |||||
36V 2600W | 36V 3000W | 36V 3000W | 36V 3800W | 36V 4200W | |||||
48V 3400W | 48V 4000W | 48V 4000W | 48V 5000W | 48V 5400W | |||||
Rated Output Current | 60A | 70A | 80A | 90A | 100A | ||||
Rated DC Load Current | 60A | ||||||||
Self Consumption | 2W | ||||||||
Max Conversion Efficiency | 98.5% | ||||||||
Protection | PV array short circuit, over charging, battery reverse polarity, output short circuit | ||||||||
Battery Type | Sealed Gel AGM Flooed Lithium | ||||||||
Charge Algorithm | Bulk, Absorption, Float, Equalize charging | ||||||||
Bulk Charge Voltage | Sealed: 14.4V AGM 14.2V Gel:14.2V Float: 13.7V User defined: 10 - 15V | ||||||||
Float Charge Voltage | Sealed/Gel/AGM: 13.8V Flooded: 13.7V User defined: 10 - 15V | ||||||||
Equalize charge Voltage | Sealed 14.6V AGM: 14.8V Flooded: 14.9V | ||||||||
Load Disconnect Voltage | 12.5V | ||||||||
Communication Port | RS485; RS232(for optional) | ||||||||
Net Weight | 6.5KG | 7.8KG | 7.8KG | 9.0KG | 9.0KG | ||||
Gross Weight | 7.3KG | 8.7KG | 8.7KG | 10KG | 10KG | ||||
Dimension | 330*230*110 | 350*230*110 | 485*320*215 | ||||||
Enclosed | IP 45 | ||||||||
Ambient Opereting Temp | -25℃~60℃ | ||||||||
Storage Temp. | -40℃~80℃ | ||||||||
Warranty | 2 years | ||||||||
Detailed Images
Application Case
Packing & Shipping
Why Choose Us
