Ведро/цилиндр/машина для розлива воды в бутылки

FILL-PACK can provide you the most professional and highest quality barrel water bottling machine.

1. This barrel water bottling machine specially produces 3&5 gallons barreled drinking water.
2. This series barreled filling production line integrates bottle washer, filler and sealer into one unit.
3. In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically.
4. This filling line equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.
5. It has features of complete functional, novel design, and high degree of automation. It is a new kind of barreled water auto- producing line, which integrates mechanism, electricity and pneumatics technologies together.

1, This barrel water bottling machine is driven by cylinder, controlled by PLC; Automatic working by barrel checking;
2, De-capping head is composed by claw device and cylinder, de-capping head position can move up and down, claw device can be adjusted slightly to be suitable for different caps.
3, When the gallon bottle comes into the machine, the de-capping head will go down and claw device will hold tightly barrel cap sides, and then lift the barrel to take off the caps; And when the caps are taken off, the compressor air will blow the caps into cap hopper, then fall outside into client's own holder;
The claw pressure is adjusted to protect caps.

1, The barrel water bottling machine is completely blocked to stop water leakage, when the gallon bottles are sent to washing position, the cylinder will increase the inner washers and insert into bottles, when the bottles are fixed by all brushes, the water will be pumped and jetted to bottle body, bottle rotates together with brushes; The bottles will be cleaned by brushes and water function;

2, No air compressor needed, it is easy for production and maintenance.

Washer/Filler/Capper with auto bottle loading

The barrel water bottling machine is integrated washing filling and capping together. It is ideal machine to produce barrel water. The whole machine is using stainless steel 304 ,rot resistant,can be cleaned easily.Main electric parts are all branded. Air channel system use Air TAC brand product.The machine is with compact construction,will occupy small room,working efficiency is high.Only need 2 operators to control, is a good choice for factory to choose.

Heat Shrinking Machine

Whole SUS304 construction, Including electrical boiler to generate steam and shrink tunnel specially for barrel cap film;

3L / 5L / 10L mineral water plastic bottle 2 in 1 washer filler capper equipment / plant / machine / system / line

bottle washer filler capper line

10liter - 20 liter semi auto blow molding machine with 1 cavity

Pure Drinking / Drinkable water RO/ Reverse Osmosis purifying equipment / plant / machine / system / line

the Barrel water bottling machine is packed by wooden case.

ZhangJiaGang City FILL-PACK Machinery Co.,Ltd. is loacated in Zhangjiagang city which is famous for beverage machinery producer collection. Intergrated the industry advantange and its own development in R&D, production, sales, after sales service, FILL-PACK is ready to serve more and more customers with our full range products and satified service.

FILL-PACK product is very critical in the choice of raw materials and spare parts. Korea 304 /316 stainless steel plate, ABB, SEW motors, Siemens, Mitsubishi, OMRON electrical control components, FESTO CAMOZZ the control valve, as well as international precision machining center for the fine quality of the machine foundation.

We are the supplier who can design and manufacture for all kinds beverage production plant(pure drinking water, mineral water, carbonated drinks, juice, tea and beer, etc.)

Customer's service:
1. FILL-PACK company can provide turn-key project for you, only you have any idea to start beverage factory plant.

2. FILL-PACK company have professional design team, our engineer can draw bottle samples and flow chart ofworkshop for you .

3. FILL-PACK company give you the best quotation for all kinds of beverage production, only you can tell me whichkind of drink you want to product, what is your capacity(how many bottles one hour) what is you bottle material, pet or glass,etc

After service:

1. We send the engineers to help installing, commissioning and training, the engineers start from our factory area.

2. We supply below necessary documents with the machine:
    a. Machine layout
    b. Electricity diagram
    c. Machine certificate
    d. General manual book/maintenance book

3. After one year guarantee, the seller provides payable spare parts and technician's VISITING maintenance service.
