Уличный фонарь 15 метров на солнечной энергии от
- Категория: Lamp Poles >>>
- Поставщик: Shaanxi,Yahua,Lighting,Electric,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.31 $* | 0.87 $* |
| Aug-16-2025 | 0.44 $* | 0.18 $* |
| Jul-16-2025 | 0.40 $* | 0.91 $* |
| Jun-16-2025 | 0.56 $* | 0.59 $* |
| May-16-2025 | 0.92 $* | 0.86 $* |
| Apr-16-2025 | 0.73 $* | 0.41 $* |
| Mar-16-2025 | 0.37 $* | 0.86 $* |
| Feb-16-2025 | 0.70 $* | 0.47 $* |
| Jan-16-2025 | 0.93 $* | 0.93 $* |
Характеристики
Product Description
China Supplier solar power energy 15 meter street light pole
Pole Height: 3M to 15M,
All Pole designs will withstand a gusted wind velocity of 150 KM/H
1.All materials utilized by Pole meet or exceed international. Standards or on Customize Request.
2.Poles are produced using steel, "self weathering" steel Q235B SS400, Q235, (yield strength: 235Pa 24kg/mm2 Tensile Strength: 375-460Pa 38-47kg/mm2
| Type | Street Lamp pole, lamp post, Lamp column, Street Light Pole |
| Shape | Conoid ,Multi-pyramidal,Columniform,polygonal or conical |
| Material | Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490ST52 |
| Torlance of dimenstion | ±0.02 |
| Design Load in Kg | 300~ 1000 Kg appliced to 50cm from the to pole |
| Surface treatment | Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required. |
| Standard | Octagonal tapered column Conforms to Standard: Pole design : BS EN 40 Material : BS EN 10025 S275 / JIS G3101 SS400 Welding : BS 5135 Galvanizing : BS 729 / ISO 1461 ASTM A 123 |
| Length of per section | Within 14m once forming without slip joint. |
| Suit for | Highway Roadway Residential subdivisions Commercial development |
| Option | Height from 6m to 12m Flange mounted or planted type Variable arm length from 0.125m to 3.0m with single or double arm type Variable spigot size from 35mm to 60mm. |
| Production Process | Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→ Dimension verify →Flange welding →Hole drilling →Calibration → Deburr→ Galvanization or powder coating ,painting →Recalibration →Thread →Packages |
| Packages | Our poles as normal cover by bubble pack/blanket or straw bale at the top and bottom ,anyway also can following by client required |
| Warranty | At least 20 years. |
Packaging & Shipping
