Автоматический сервофидер рулонный стальной штамповочный Nc
- Категория: Metal Straightening Machinery >>>
- Поставщик: Shenzhen,Lihao,Machinery,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 1109.49 $* | 1164.46 $* |
| Aug-15-2025 | 1100.66 $* | 1155.50 $* |
| Jul-15-2025 | 923.27 $* | 969.77 $* |
| Jun-15-2025 | 1081.43 $* | 1135.84 $* |
| May-15-2025 | 941.62 $* | 988.80 $* |
| Apr-15-2025 | 1062.83 $* | 1115.3 $* |
| Mar-15-2025 | 1053.12 $* | 1106.95 $* |
| Feb-15-2025 | 1044.37 $* | 1096.88 $* |
| Jan-15-2025 | 1035.52 $* | 1087.61 $* |
Характеристики
MAIN FEATURES
● High precision feeding: Aiming at the arrival of hi-tech industry, it is controlled by computer closed-circuit feedback system. So that the precision can maintain within +/-0.03mm.
● Phase-style feeding function: It can input 20 sets of different feeding length, each group provides punching for 999 times to satisfy the processing and production of special products (option)
● Manual model: It can input 3 phases manual speed, which can let used operate more easily and feed materials more accuracy.
● High efficiency release device: It can set up release angle quickly, only match cam signal of and adjusted feed thickness can done.
● Feeding length setting: Input feed length on the controller panel directly.
● Feeding unit: The roll adopts middle-hollow style. Being light and with low inertia for electroplate. The surface hardness HRC is 58 and hard chrome plated.
Thin Board Model
MODEL | NC-200 | NC-300 | NC-400 | NC-500 |
Feed Width | 0～200mm | 0～300mm | 0～400mm | 0～500mm |
Applicable Material Thickness | 0.2～2.5mm | 0.2～2.5mm | 0.2～2.5mm | 0.2～2.5mm |
Feed Length | 0～9999.99mm | 0～9999.99mm | 0～9999.99mm | 0～9999.99mm |
Feeding Speed | 20m/min | 20m/min | 20m/min | 20m/min |
Way to Relax | Pneumatic relaxation | Pneumatic relaxation | Pneumatic relaxation | Pneumatic relaxation |
Product Packaging | Thickened wooden box | Thickened wooden box | Thickened wooden box | Thickened wooden box |
Thick Board Model
MODEL | NC-200A | NC-300A | NC-400A | NC-500A |
Feed Width | 0～200mm | 0～300mm | 0～400mm | 0～500mm |
Applicable Material Thickness | 0.3～4.5mm | 0.3～4.5mm | 0.3～4.5mm | 0.3～4.5mm |
Feed Length | 0～9999.99mm | 0～9999.99mm | 0～9999.99mm | 0～9999.99mm |
Feeding Speed | 20m/min | 20m/min | 20m/min | 20m/min |
Way to Relax | Pneumatic relaxation | Pneumatic relaxation | Pneumatic relaxation | Pneumatic relaxation |
Product Packaging | Thickened wooden box | Thickened wooden box | Thickened wooden box | Thickened wooden box |
Application Scenario
Small Equipment
