Аккумуляторный блок ручной точечный сварочный

Категория: Other Machinery & Industrial Equipment >>>
Поставщик: Xiamen,Acey,New,Energy,Technology,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-16-2025	0.62 $*	0.35 $*
Aug-16-2025	0.24 $*	0.89 $*
Jul-16-2025	0.81 $*	0.60 $*
Jun-16-2025	0.27 $*	0.26 $*
May-16-2025	0.59 $*	0.18 $*
Apr-16-2025	0.91 $*	0.33 $*
Mar-16-2025	0.73 $*	0.78 $*
Feb-16-2025	0.84 $*	0.1 $*
Jan-16-2025	0.65 $*	0.21 $*

Характеристики

quyu (1).jpg

Battery Pack Manual Spot Welding machine Gantry spot welder

quyu (2).jpg

Description:

ACEY-1000C equipped with advanced 220V AC welding power supply, Suitable for battery pack spot welding and assembly in the factory. It can assembling batteries like 18650, 26650, 21700... and Nickel or Nickel-Plated Steel strips. Which support battery pack like E-Bike, Scooter, electromobile ...

*This type of AC spot welder utilizes the general mains supply to lower the voltage and increase the electric current. Such kind of low voltage but large current will be transmitted from the electrode to the linked point of two work pieces.
*On the linkage, due to the resistance of work piece, high temperature will occur so the metal will therefore generates high heat to make the work pieces in molten condition.

Energy storage capacitor	6600UF
Max output power of transformer	18 KVA
Output max short circuit current	5000A
Prewelding voltage	80.0V -- 330V adjustable, accuracy 0.5V
Welding voltage	80.0V -- 330V adjustable, accuracy 0.5V
Welding time	1.0ms -- 20.0ms adjustable, accuracy: 0.1ms
Applicable scope	Max thickness of parallel welding: 0.03mm~0.2mm Max thickness of upper and lower butt welding: 0.3mm + 0.5mm
Machine weight	40KG
Dimensions	350L x 180W x 280H (unit: mm)
Input power supply	single-phase AC220V/50Hz
Input current	< 5A
Input power	< 1200W
