Высокомачтовые прожекторные светильники осветительная башня 15 метров уличный
- Категория: Lamp Poles >>>
- Поставщик: Yantai,Lu,Hao,Lighting,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 55.54 $* | 58.88 $* |
| Aug-18-2025 | 54.80 $* | 57.49 $* |
| Jul-18-2025 | 46.44 $* | 48.78 $* |
| Jun-18-2025 | 53.64 $* | 56.60 $* |
| May-18-2025 | 46.88 $* | 48.85 $* |
| Apr-18-2025 | 52.58 $* | 55.21 $* |
| Mar-18-2025 | 52.46 $* | 55.46 $* |
| Feb-18-2025 | 52.55 $* | 55.23 $* |
| Jan-18-2025 | 51.44 $* | 54.17 $* |
Характеристики
Specification
Height | From 3 m to 25 m |
Suit for | Airport ,seaport,plaza,stadium ,square,highway,street way etc |
Shape | Conoid ,Multi-pyramidal,Columniform,polygonal or conical |
Material | Usually Q345B/A572, Q235B/A36,As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52- |
Lamp power | 20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz |
Torlance of the dimenstion | +- 2% |
Optical assembly of lighting fixture | IP 65 |
Electroshock resistant protective grade | Grade one |
The casing anti-corrosion performance | Class two |
Working atmosphere of lighting fixture | -35 °C~+45 °C |
Surface treatment | Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required. |
Joint of Poles | Insert mode,innerflange mode,face to face joint mode |
Design of pole | Against earthquake of 8 grade |
Wind Speed | 160 Km/Hour |
Minimum yield strength | 355 mpa |
Minimum ultimate tensile strength | 490 mpa |
Max ultimate tensile strength | 620 mpa |
Standard | ISO 9001 |
Length of per section | Within 12m once forming without slip joint |
Welding | We has past flaw testing.Internal and external double welding makes the welding beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1 |
Thickness | 1 mm to 30 mm |
Production Process | Rew material test → Cuttingj →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration → Deburr→Galvanization or powder coating ,painting →Recalibration →Thread →Packages |
Packages | Our poles as normal cover by Mat or straw bale at the top and bottom ,anyway also can following by client required , each 40HC or OT can loading how many pcs will calculation base on the client actually specification and data. |
Style | Size and styles are veriable as per customer request |
Product Description
IP65 Waterproof Solar LED Street Light 30W 40W 60W 80W 100W 120W All In One Integrated Solar Street Light system with Motion Sensor
Packing & Delivery
Company Profile
Certifications
Exhibition
Product Process
FAQ
Q1. Can I customize the light hours and brightness of the all in one LED solar street light product?
A1: Yes, our professional engineers will make the setting according to your requirements.
Q2. Can I have the all in one LED solar street light product without the sensor?
A2: Yes, All the LED solar street lights in all wattage can be made without the sensor, we will settimer-control for the lamps.
Q3. Can I use the all in one LED solar street light product on the islands?
A3: Yes, they are Anti-Tyhpoon/hurricane design with anti-rust treatment, which can be used in harsh environments such as islands, coasts, and lakeside.
Q4. Can I have a sample order for the all in one LED solar street light product?
A4: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q5. What about the lead time?
A5:We could send sample for you within 7
working days, mass production time needs 1-2 weeks for order quantity more than 200pcs.
Q6: Do you offer guarantee for the products?
working days, mass production time needs 1-2 weeks for order quantity more than 200pcs.
Q6: Do you offer guarantee for the products?
A6: Yes, we offer a standard 3-year warranty to our all in one LED solar street light product, a 5-year warranty is optional.
Q7. How do you ship the goods and how long does it take to arrive?
A7: We usually ship by DHL, UPS, FedEx or TNT for sample orders. It usually takes 3-5 days to arrive. Airline and sea shipping is preferable for bulk order.
Q8. How to proceed an order for all in one LED solar street light?
A8: Firstly, Let us know the mode number and the quantity you want to order or tell us your requirements on the all in one LED solar street light. Secondly, We will quote accordingly.Thirdly, a proforma invoice(PI) will be sent to you after you confirm the item and quantity so you can arrange the payment. Fourthly, We arrange the production and make
shipment.
shipment.
Q9. Is it OK to print my logo on the all in one LED solar street light product?
A9: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q10: How to deal with the faulty?
A10: Firstly, Ourproducts are produced in strict quality control system and the defective rate will be less than 0.1%. Secondly, during theguarantee period, we will send new lights or parts with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
