Промышленная машина для просеивания специй вибросита очистки

Промышленная машина для просеивания специй вибросита очистки

Категория: Separation Equipment >>>
Поставщик: Xinxiang,Gaofu,Machinery,Co.,Ltd.

Цена:1 800,00 $ - 1 880,00 $*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-15-2025	2142.93 $*	2249.97 $*
Aug-15-2025	2124.37 $*	2230.34 $*
Jul-15-2025	1782.82 $*	1871.92 $*
Jun-15-2025	2088.81 $*	2192.75 $*
May-15-2025	1818.28 $*	1909.24 $*
Apr-15-2025	2052.28 $*	2155.7 $*
Mar-15-2025	2034.85 $*	2136.14 $*
Feb-15-2025	2016.38 $*	2117.91 $*
Jan-15-2025	1998.6 $*	2098.75 $*

Характеристики

Product Description

Specification

Model	Effective diameter (mm)	Sieve area (m2)	Mesh	Layer	Power(KW)
Model	Effective diameter (mm)	Sieve area (m2)	Mesh	Layer					Vibration motor	Common motor
S49-400	Φ340	0.0907	2-500	1-5	0.18	------
S49-600	Φ540	0.2289					0.25	0.75
S49-800	Φ730	0.4183					0.55	1.1
S49-1000	Φ900	0.6359					1.1	1.5
S49-1200	Φ1100	0.949					1.1	1.5
S49-1500	Φ1400	1.5386					1.5	2.2
S49-1800	Φ1700	2.2687					4	3
S49-2000	Φ1886	2.7922					4	3

S49-A series slurry vibro sieve use upright motos as the source of vibration ,equipped eccentricity hammer on the both sides of motor,change circumtotate to horizontal ,vertical and inclined movement ,then pass these three movement to the surface of the screen .Adjust the angle on the both sides of the top and bottom to change the movement orbits of the surface screen .

Observation hole / Dust collection hole :

1，Observe the operation of materials ,adjust the excitation force of the equipment in time to ensure the effect of equipment operation .

2,Supporting dust removal equipment to prevent dust from flying and protect employee health.

Screen Frame：

1，A variety of screen frame forms are available to meet the needs of different materials .

2, Easy to replace the screen.

Gate

1，Freely control the discharge speed and quantity of materials .

2,Convenient for customers to clean the screen surface.

Cleaning device：

1,Classic mesh cleaning device , a variety of materials available to meet the needs of different industries.

2, Bouncing ball matched with the ring, the mesh cleaning effect is obvious ,and the cleaning performance is super high.

Fuma Wheel :

1, International size ,high -quality nylon,thick and wear-resistant,stable and easy driving.

2,The screw setting is easy to expand and contract,just turn up and down by one turn.

3,Thicker bracket, more stable and convenient to use .

Vibration motor ：

Self-produced vibration motor， meet with explosion-proof standards,stable performance and convenient maintenance.

Food industry

Pharmaceutical industry

Filtration

Feed

Powder coating

Pigment

Plastic

Battery material

Metallurgy

Packing & Delivery

Company Profile

Gaofu Machinery factory and team

Xinxiang Gaofu Machinery has more than 30 years of growth history .Our factory was listed on the New OTC Market in 2016(stock code :836946).The company's brand "Gaofu" is a China Well-known Trademark", and it has won the "Henan Famous Trademarks "at the same time .It has a scientific and technological achievement award issued by the Ministry of Industry and Information Technology.With hundreds of patents for inventions, utility models and appearance.

Our factory main business is the development and sales of vibration machinery ,screening equipment,coal crushing machine and filtering equipment,conveying and feeding machine .The products are not only hot sale in China ,but also exported to 68 countries and regions ,eg : USA ,UK ,Canada ,Spain ,France ,Australia, Indonesia，Thailand，etc .
