Новый заказ гидравлический мини-Гусеничный мини-экскаватор для
- Категория: Engineering & Construction Machinery >>>
- Поставщик: ZHENGZHOU,E.P,MACHINERY,CO.,LTD
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 3189.74 $* | 3348.72 $* |
| Aug-16-2025 | 3162.67 $* | 3320.32 $* |
| Jul-16-2025 | 2653.78 $* | 2786.75 $* |
| Jun-16-2025 | 3109.31 $* | 3264.89 $* |
| May-16-2025 | 2707.32 $* | 2842.86 $* |
| Apr-16-2025 | 3055.11 $* | 3208.4 $* |
| Mar-16-2025 | 3028.90 $* | 3179.82 $* |
| Feb-16-2025 | 3002.85 $* | 3152.26 $* |
| Jan-16-2025 | 2975.67 $* | 3124.78 $* |
Характеристики
Products Description
Brief Introduction
Mini excavators, also called compact excavators, mini diggers, are tracked or wheeled vehicles with operating weight of
approximately 0.7 to 8.5 tons. It usually includes a standard backfill blade and has an independent cantilever swing.
Mini excavators are totally different from other construction equipment that all the movements and functions of the machine are accomplished by the driven of hydraulic fluid. The workgroup and blade of the compact excavator are driven by hydraulic oil acting on hydraulic cylinders. The swing (rotation) and travel functions of the excavator are also activated by hydraulic motors powered by hydraulic fluid.
The workgroup of a compact hydraulic excavator consists of a boom, bucket or arm and attachments such as augers, buckets or breakers. It is attached to the front of the excavator housing structure via a swing frame that allows the workgroup to hydraulically pivot left or right for offset excavation and trenching parallel to the track.
approximately 0.7 to 8.5 tons. It usually includes a standard backfill blade and has an independent cantilever swing.
Mini excavators are totally different from other construction equipment that all the movements and functions of the machine are accomplished by the driven of hydraulic fluid. The workgroup and blade of the compact excavator are driven by hydraulic oil acting on hydraulic cylinders. The swing (rotation) and travel functions of the excavator are also activated by hydraulic motors powered by hydraulic fluid.
The workgroup of a compact hydraulic excavator consists of a boom, bucket or arm and attachments such as augers, buckets or breakers. It is attached to the front of the excavator housing structure via a swing frame that allows the workgroup to hydraulically pivot left or right for offset excavation and trenching parallel to the track.
Product Paramenters
Specifications of Performance | ||||||
Operation Weight | 900 KG | Power | 9.5 HP | |||
Bucket Digging Force | 10.3 KN | Engine Model | KOOP KD192F-1 | |||
Working Device | Backhoe | Single Cylinder | ||||
Bucket Volume | 0.025 M3 | Air Cooled | ||||
Main Dimensions | ||||||
Overall Dimensions | 2210x920x2220 MM | Track Height | 320 MM | |||
Chassis Width | 920 MM | Track Width | 180 MM | |||
Track Length | 1215 MM | Min. Ground Clearance | 140 MM | |||
Operating Range | ||||||
Max. Digging Depth | 1640 MM | Max. Digging Height | 2640 MM | |||
Min. Swing Radius | 1290 MM | Max. Digging Radius | 2890 MM | |||
Max. Dumping Height | 2000 MM | Max. Height of Dozer Blade | 180 MM | |||
Details Images
Multi-function Use
Our Advantages
Company Profile
Customers Feedback
