Станок с ЧПУ высокоскоростной низкоскоростной стальной
- Категория: Metal Straightening Machinery >>>
- Поставщик: Contrust,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 4046.4 $* | 4248.41 $* |
| Aug-18-2025 | 4012.87 $* | 4213.29 $* |
| Jul-18-2025 | 3366.54 $* | 3534.76 $* |
| Jun-18-2025 | 3944.63 $* | 4141.70 $* |
| May-18-2025 | 3434.87 $* | 3606.8 $* |
| Apr-18-2025 | 3876.42 $* | 4070.79 $* |
| Mar-18-2025 | 3842.1 $* | 4034.88 $* |
| Feb-18-2025 | 3808.75 $* | 3998.49 $* |
| Jan-18-2025 | 3774.23 $* | 3963.63 $* |
Характеристики
Products Description
This CNC hydraulic bar straightening and cutting machine is used for straightening and straightening the cutting of steel and steel bars of the building with cold rolling, the failure rate of the equipment is low, and the traction speed is high,This machine is low consumption, no damage of rib, low noise, vibration, and is equipped with safety device, automatic counting parking device, has high production efficiency, safe and reliable work, equipment and other significant characteristics of low failure rate, simple product maintenance.
1) The equipment is mainly used for automatically straighten stainless steel wire, galvanized wire, aluminum wire, cooper wire, and cut automatically according to the preset length.
2) Automatic wire straightening and cutting machine operation and maintenance are simple. It is mainly used for straightening and cutting the wire with diameter less than 6mm and the maximum cutting length is less than 2 metres.(But we can set the length of wire according to customer's requirement).
3) It has the functions of automatic counting, pre-setting cutting amount, stop working after finished working and etc. Compared with other suppliers, the straightening frame uses hot rolling process, better appearance, stronger rigidity and better straightening result.
4) The hydraulic system is simple and reliable, no leak oil and no blocking.
5) Faster straightening and cutting speed. As using the CNC system, the speed can be adjustable according to the users' requirement.
6) More higher sizing accuracy. It uses importing CNC cutting controlling, zero error cutting and saved more materials.
2) Automatic wire straightening and cutting machine operation and maintenance are simple. It is mainly used for straightening and cutting the wire with diameter less than 6mm and the maximum cutting length is less than 2 metres.(But we can set the length of wire according to customer's requirement).
3) It has the functions of automatic counting, pre-setting cutting amount, stop working after finished working and etc. Compared with other suppliers, the straightening frame uses hot rolling process, better appearance, stronger rigidity and better straightening result.
4) The hydraulic system is simple and reliable, no leak oil and no blocking.
5) Faster straightening and cutting speed. As using the CNC system, the speed can be adjustable according to the users' requirement.
6) More higher sizing accuracy. It uses importing CNC cutting controlling, zero error cutting and saved more materials.
The straightening machine is composed of a frame, a straightening mechanism, a feeding mechanism, a cutting mechanism, a linear gun and a wire frame.
The straightening part is composed of a straightening shaft, a straightening pressing block and two bearing blocks to complete the straightening work of the wire, the power is the motor mounted under the machine frame, and the straightening shaft is rotated at a high speed by the triangular tape.
Specification
Model | GT4-14 | GT5-14 | GT6-14 | ||
Straightening Steel Bar Diameter | 5-14mm | 5-14mm | 6-14mm | ||
Cut Length | 650-8500mm | 650-8500mm | 650-8500mm | ||
Total power | 9KW | 17KW | 24KW | ||
Voltages | 220V / 380V / Customized | ||||
Straightening Speed | 45 - 65m / min | 45 - 65m / min | 65 - 80m / min | ||
Details Images
Digital control panel
Straightening cutting machine makes mechanical cutting more precise and the error is controlled within 0.2 mm.
Side cutter
Low oil temperature, fast tooling, wear resistance, more stable.
Digital control panel
Straightening cutting machine makes mechanical cutting more precise and the error is controlled within 02 mm.
High speed traction wheel
One set traction wheel in front of straight frame, two sets traction wheel behind of straight frame.
Total three sets of traction make steel bar more straight.
Full copper motor
Double tubing cylinder
No damage feed inlet
Application
Wire Straightening and Cutting Machine is specially used for automatically straighten stainless steel wire, galvanized wire, aluminum wire, cooper wire, and cut automatically according to the preset length.
Material: Stainless steel wire, alloy steel wire, low/middle/high carbon steel wire.
FAQ
● What is the Minimum Quality Order?
-- The MOQ is 1 set. If you order large amount, you will get discount.
● What is the payment terms?
-- T/T, L/C, Western Union,credit card.
● Which kind of shipment do you support?
-- Sea transportation, air transportation and international express.
● When will you deliver the machine?
-- 7-15 workdays after receiving the balance payment.
● Do you supply training and after-sale service?
-- Yes, we will supply installation and training on site or online. Also we have a professional service team that can solve problems as fast as possible.
● What about the warranty time of machine?
-- 12 months after shipment.
-- The MOQ is 1 set. If you order large amount, you will get discount.
● What is the payment terms?
-- T/T, L/C, Western Union,credit card.
● Which kind of shipment do you support?
-- Sea transportation, air transportation and international express.
● When will you deliver the machine?
-- 7-15 workdays after receiving the balance payment.
● Do you supply training and after-sale service?
-- Yes, we will supply installation and training on site or online. Also we have a professional service team that can solve problems as fast as possible.
● What about the warranty time of machine?
-- 12 months after shipment.
Company Profile
Certifications
Packing details:
Standard export package.
Delivery time:
5-10 days 1 set after payment. The delivery time of bulk products depends on the quantity of machines.
