Интеллектуальная балансировочная плата BMS 4A активный эквалайзер 24 серии литий-титанат тройник железо-литиевый без потерь управление через
- Категория: Battery Repair Device >>>
- Поставщик: Dongguan,Mannya,Clothing,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-20-2025 | 108.97 $* | 110.12 $* |
| Jul-20-2025 | 88.9 $* | 90.97 $* |
| Jun-20-2025 | 106.24 $* | 108.94 $* |
| May-20-2025 | 105.91 $* | 107.59 $* |
| Apr-20-2025 | 84.18 $* | 86.45 $* |
| Mar-20-2025 | 104.10 $* | 106.89 $* |
| Feb-20-2025 | 103.38 $* | 105.55 $* |
| Jan-20-2025 | 102.36 $* | 104.33 $* |
Характеристики
Product Description
Specification
item | value |
Place of Origin | China |
Guangdong | |
Brand Name | GWbms |
Model Number | 4a 24s |
Warranty | 3months-1year |
Type | Active equalizer |
Certification | no |
Voltage | 1-4.5v |
Customized | Yes |
Dimension | 144*128*22.5mm |
MOQ | 1 |
Shipment Terms | Customer decides |
1-Applicable string number: 10~24S
2-Applicable battery type: NCM/LFP/LTO (ternary/lithium iron/lithium titanate) fully compatible
3-Power supply range Applicable number of strings: The minimum total voltage of the battery pack is greater than 30V, the recommended value: ternary battery ≥ 10 strings, iron-lithium battery ≥ 12 strings, LTO battery ≥ 20 strings
4-cell voltage working range: 1.0~4.5V
5-Voltage balance accuracy: ±1mv (voltage measurement accuracy), ±1mv (voltage balance accuracy), this product is calibrated by Keithley DMM7510
6-Equalization method: Patented equalization structure flying capacitor method, combined with point-to-point energy transfer algorithm for high-efficiency equalization.
7-Equalization current: APP custom setting: 1-4A, due to the use of constant current and constant voltage technology, the equalization current has nothing to do with the battery voltage difference.
8- Drop detection: support
9-Under-voltage protection sleep voltage: Under-voltage sleep voltage can be customized by APP: 1.5-4.2V
10-Static working current: Balanced off 10mA, balanced on 25mA
11-Product size (MM): L140*W128*T22
12-Working environment temperature -20 degrees to +55 degrees
13-Whether an external power supply is needed: No external power supply is needed, and the whole group is balanced by the internal energy transfer of the battery
2-Applicable battery type: NCM/LFP/LTO (ternary/lithium iron/lithium titanate) fully compatible
3-Power supply range Applicable number of strings: The minimum total voltage of the battery pack is greater than 30V, the recommended value: ternary battery ≥ 10 strings, iron-lithium battery ≥ 12 strings, LTO battery ≥ 20 strings
4-cell voltage working range: 1.0~4.5V
5-Voltage balance accuracy: ±1mv (voltage measurement accuracy), ±1mv (voltage balance accuracy), this product is calibrated by Keithley DMM7510
6-Equalization method: Patented equalization structure flying capacitor method, combined with point-to-point energy transfer algorithm for high-efficiency equalization.
7-Equalization current: APP custom setting: 1-4A, due to the use of constant current and constant voltage technology, the equalization current has nothing to do with the battery voltage difference.
8- Drop detection: support
9-Under-voltage protection sleep voltage: Under-voltage sleep voltage can be customized by APP: 1.5-4.2V
10-Static working current: Balanced off 10mA, balanced on 25mA
11-Product size (MM): L140*W128*T22
12-Working environment temperature -20 degrees to +55 degrees
13-Whether an external power supply is needed: No external power supply is needed, and the whole group is balanced by the internal energy transfer of the battery
