4*2 Isuzu Fire Car 3Ton Fighting Vehicle 100p Engine Truck at BIG
- Категория: Fire Trucks >>>
- Поставщик: Hubei,Xindongri,Special,Vehicle,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 31083.0 $* | 31705.75 $* |
| Jul-18-2025 | 25209.41 $* | 25713.69 $* |
| Jun-18-2025 | 30594.53 $* | 31206.49 $* |
| May-18-2025 | 30349.37 $* | 30956.40 $* |
| Apr-18-2025 | 24230.70 $* | 24715.66 $* |
| Mar-18-2025 | 29860.64 $* | 30457.47 $* |
| Feb-18-2025 | 29615.37 $* | 30207.96 $* |
| Jan-18-2025 | 29370.97 $* | 29957.36 $* |
Характеристики
Product Description
Contact Supplier for a FREE Sample!
https://message.alibaba.com/msgsend/contact.htm?spm=a2700.galleryofferlist.normal_offer.8.6f6516d0qTqqef&action=contact_action&appForm=s_en&chkProductIds=60710985371&chkProductIds_f=IDX1CjFiu7dUOHVLUcc1hCTH7E0k7DlecOlkO4eWv4T7YnQoNuJ4nIav13TNPj7NwW1O&tracelog=contactOrg&mloca=main_en_search_list
Specification
Item | Water Tank Fire Truck | Chassis Brand | Isuzu | ||||||
Vehicle parameters | GVW(kg) | 6800 | Overall Dimension (mm) | 6390×1960×2950 | |||||
Rated load (kg) | 2035 | Steering Wheel | LHD | ||||||
Curb weight (kg) | 4400 | Wheelbase (mm) | 3360 | ||||||
Driving Type | 4*2 | ||||||||
Engine parameters | Model | 4JB1CN | Emission Standard | Diesel, Euro 3 | |||||
Horse Power（hp） | 98 | Emissions(ml) | 2771 | ||||||
4 stroke,4-cylinders in line, turbo charged and inter-cooling | |||||||||
Gear box | 6 forward and 1 reverse | ||||||||
Performance Parameter | Max Speed (km/h) | 95 | Wheel Tread(mm) | Front Axle | 1504 | ||||
Cab Seat | 2+3 | Rear Axle | 1425 | ||||||
Leaf Spring | 8/6+5 | Suspension (mm) | Front Suspension | 1015 | |||||
Tire No. | 6 | Rear Suspension | 1900 | ||||||
Tire Specification | 7.00R16 | Driving Angle(°) | Approach Angle | 24 | |||||
Axle No. | 2 | Departure Angle | 13 | ||||||
Special Function | Capacity | Water tank 3000L | |||||||
Fire Pump | 1. CB10/20, 20L/S,pressure:1.0MPa 2.Suction time≤ 35s（7m suction depth ）centrifugal pump | ||||||||
Fire Monitor | 1.PS20, 20L/S, pressure: 1.0Mpa 2. Fire nozzle range: water≥48m | ||||||||
Performance Description | Double row cab(Can be customized); ABS, Air conditioning system. Hidden tank, material is carbon steel Q235A，with thickness 4 mm; Truck body with aluminum alloy rolling door； PTO control indicator installed in cab, also with 100W siren, LED alarm lamp, sign light, lighting switch, rear lighting and etc. Fire equipments are included. | ||||||||
