Высокоточный Настольный Двойной Жидкий робот силиконовый автоматический диспенсер клея Smt
- Категория: Other Machinery & Industry Equipment >>>
- Поставщик: Guangzhou,Kintai,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.81 $* | 0.8 $* |
| Aug-18-2025 | 0.38 $* | 0.79 $* |
| Jul-18-2025 | 0.50 $* | 0.6 $* |
| Jun-18-2025 | 0.83 $* | 0.94 $* |
| May-18-2025 | 0.81 $* | 0.7 $* |
| Apr-18-2025 | 0.30 $* | 0.31 $* |
| Mar-18-2025 | 0.81 $* | 0.95 $* |
| Feb-18-2025 | 0.92 $* | 0.68 $* |
| Jan-18-2025 | 0.17 $* | 0.39 $* |
Характеристики
Products Description
KTS-400 Bench Top Fluid Dispensing Robot
Features:
1.Computer Control, Windos OS;
2.Servo Motor + Ball Screw Driven;
3.X,Y,Z robotic arms repeatability accuracy up to 0.015mm;
4.Hidden PC design, compact external dimension;
5.Dispensing bench with Vacuum absorption function;
6.Visual dispensing patterns,easy programming;
Products Parameters
MODEL | KTS-400 Glue Dispensing Machine | ||||||
Repeatability Accuracy | ±0.015mm/Axis | ||||||
X/Y/Z Working Dispensing Range | X400mm * Y400mm * Z100mm | ||||||
XY/Z Speed | Max:800/500 (mm/s) | ||||||
Motion/Drive System | Servo Motor, Ball Screw, Linear Slide | ||||||
Control Method | Industrial Computer + Motion Controller + LCD Display | ||||||
Positioning | 300,000 Resolution CCD Vision Camera | ||||||
Material Supply(customized) | Glue Tank(2600ml optional) 5cc/10cc/30cc/50cc Cartridge(optional) 30cc syringe | ||||||
Laser Height Measurement | Automatic Laser Height (precision:0.001mm) Detection & Z Axis Height Calibration Optional | ||||||
Power Supply | AC 110/220V, 50/60Hz, 1Kw | ||||||
Air Pressure | 0.5-0.7Mpa, 0.2m²/h | ||||||
CAD Impot | DXF Format | ||||||
Low Fluid Sensor/Warning | Optional | ||||||
Memory Capacity | 1000 Programs - Unlimited (Data Storage via USB) | ||||||
Company Profile
Production Process
Cer and Exhibition
Order and feedback
Product Packaging
FAQ
