10A 20A 30A 40A 50A 60A PWM USB контроллер заряда солнечной батареи интеллектуальный регулятор 12 В
- Категория: Solar Charger Controllers >>>
- Поставщик: Shenzhen,Xiongfa,Weiye,Electronics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.28 $* | 0.63 $* |
| Aug-17-2025 | 0.5 $* | 0.11 $* |
| Jul-17-2025 | 0.70 $* | 0.84 $* |
| Jun-17-2025 | 0.31 $* | 0.71 $* |
| May-17-2025 | 0.82 $* | 0.33 $* |
| Apr-17-2025 | 0.20 $* | 0.31 $* |
| Mar-17-2025 | 0.53 $* | 0.97 $* |
| Feb-17-2025 | 0.59 $* | 0.15 $* |
| Jan-17-2025 | 0.16 $* | 0.36 $* |
Характеристики
Features:
1. Three stage PWM regulation charging: This product adopts direct charging, lifting charging and floating charging three stage PWM regulation
charging modes. Using the controller to achieve efficient and fast intelligent charging, and effectively extend the service life of the battery.
2. Automatically manage: Automatically manage the works of solar panel and battery in solar system.
3. Overload and short circuit protection: It has built-in short circuit protection, open circuit protection, reverse protection, overload protection.
4. Practical: This product can extend battery life and keep load working properly.
5. Good quality: This product is made of high-quality materials, exquisite workmanship, very good quality and long service life.
Display:
MENU:switch between different display,or to enter/exit setting by long press.
UP: press to increase value.
DOWN: presss to decrease value.
Setting:
1.press the [Down] button to ON/OFF load manully at main display.
2.the work mode is working as below:
[24H] load output 24hours
[1-23H] load on after sunset and closed after setting hours
[0H] Dusk to dawn
Description:
This is very popular solar charger controller, it can be used for 12V 24V Lead acid, gel, AGM, Flood, Sealed Batteries
Specifications:
Model Name: W88-C(10A)
Rated Charge Current:10A
System Voltage: 12/24V AUTO
Max. PV open circuit voltage: 50V(24V System) 25V(12V System)
Max. PV input power: 130W when your battery is 12V; 260W when your battery is 24V
Model Name: W88-C(20A)
Rated Charge Current:20A
System Voltage: 12/24V AUTO
Max. PV open circuit voltage: 50V(24V System) 25V(12V System)
Max. PV input power: 260W when your battery is 12V; 520W when your battery is 24V
Model Name: W88-C(30A)
Rated Charge Current:30A
System Voltage: 12/24V AUTO
Max. PV open circuit voltage: 50V(24V System) 25V(12V System)
Max. PV input power: 390W when your battery is 12V; 780W when your battery is 24V
Model Name: W88-C(40A)
Rated Charge Current:40A
System Voltage: 12/24V AUTO
Max. PV open circuit voltage: 50V(24V System) 25V(12V System)
Max. PV input power: 520W when your battery is 12V; 1040W when your battery is 24V
Model Name: W88-C (50A)
Rated Charge Current:50A
System Voltage: 12/24V AUTO
Max. PV open circuit voltage: 50V(24V System) 25V(12V System)
Max. PV input power: 600W when your battery is 12V; 1200W when your battery is 24V
Model Name: W88-C (60A)
Rated Charge Current: 60A
System Voltage: 12/24V AUTO
Max. PV open circuit voltage: 50V(24V System) 25V(12V System)
Max. PV input power: 720W when your battery is 12V; 1440W when your battery is 24V
