Sinotruk SINOTRUCK HOWO 4X2 6x4 8X4 форма и водный Тип пожарная машина
- Категория: Fire Trucks >>>
- Поставщик: Jinan,Mettlead,Auto,Sales,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-15-2025 | 65450.87 $* | 68723.76 $* |
| Aug-15-2025 | 64900.24 $* | 68145.84 $* |
| Jul-15-2025 | 54450.36 $* | 57173.2 $* |
| Jun-15-2025 | 63800.96 $* | 66990.90 $* |
| May-15-2025 | 55550.94 $* | 58328.61 $* |
| Apr-15-2025 | 62700.79 $* | 65835.14 $* |
| Mar-15-2025 | 62150.5 $* | 65258.16 $* |
| Feb-15-2025 | 61600.46 $* | 64680.98 $* |
| Jan-15-2025 | 61050.63 $* | 64103.44 $* |
Характеристики
Company Profile
PRODUCT SPECIFICATIONS
SINOTRUK HOWO FIRE FIGHTING TRUCK | ||||||||||||
SPECIFICATION | ||||||||||||
Engine | Modal | WD615.47 | WD615.47 | D12,42 | ||||||||
Emission | Euro 2 | Euro 2 | Euro 2 | |||||||||
Displacement | 9.726L | 9.726L | 11.596L | |||||||||
Max Torque ( Nm/rpm) | 1350/1100-1600 | 1500/1100-1600 | 1820/1100-1600 | |||||||||
Type | water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling,directly injection | water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection | water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection | |||||||||
Clutch | Single-plate dry coil-spring clutch, diameter 430mm, hydraulically operating with air assistance. | |||||||||||
Transmission | SINOTRUK HW 19710 | |||||||||||
Chassis | Three layers frame 8+8+8mm,U-profile parallel ladder frame and reinforced subframe, all cold riveted cross members | |||||||||||
Front Axle | HF 9 for heavy truck, rated load of 12 t. drum-type | |||||||||||
Rear Axles | HC16 with double reduction, central single reduction plus planetary wheel reduction and with differential lock | |||||||||||
Drive Shaft | Double universal joint propeller shaft with gear-shaped coupling flange | |||||||||||
Fuel Tank | 400 L Aluminum fuel tank with locking fuel cap, fitted to the off side of the chassis | |||||||||||
Steering | ZF power steering, model ZF8118,hydraulic steering with power assistance. | |||||||||||
Braking System | Service brake: dual circuit compressed air brake. Parking brake(emergency brake):spring energy, compressed air operating on rear wheels | |||||||||||
Auxiliary brake: engine exhaust brake | ||||||||||||
Tyres | Standard is 12.00R20 | |||||||||||
Electrical System | Operating voltage | 24V,negative grounded | ||||||||||
Starter | 24V.7.5Kw | |||||||||||
Alternator | 3-phase,28V,1500W | |||||||||||
Batteries | 2*12V,165Ah/180Ah | |||||||||||
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light | ||||||||||||
Instrument | Active check central controller with indicators, with this integral instrument the daily manual checks on the vehicle | |||||||||||
combined indicators of compressed air pressure, coolant temperature, engine oil pressure | ||||||||||||
battery charging | ||||||||||||
Dimensions (mm) | Wheelbase : 3200-3400-3600-3800 mm | 3225+1350,3200+1400 | ||||||||||
Front overhang : 1500 mm | 1500 | |||||||||||
Rear overhang : 1000 mm | 725 | |||||||||||
Approach angle(°) : 32 | 16 | |||||||||||
Departure angel(°) : 40 | 70 | |||||||||||
Overall (L*W*H) mm : 8625x326x3320 | 6800*2496*3835 | |||||||||||
Weight(kg) | Curb weight : 29700 | 8800 | ||||||||||
Front axle loading capacity : 9000 | 9000 | |||||||||||
Rear axle loading capacity : 2x16000 | 18000/18000 | |||||||||||
Towable Total Mass(kg) : 50000 | 40000 | |||||||||||
Performance Parameters | Maximum driving speed(km/h) : 75 | 90-102 | ||||||||||
Economic Speed(km/h) : 60 | 72-82 | |||||||||||
Maximum Gradability(%) :35 | 35 | |||||||||||
Minimum Turning Diameter(m) : 4520 | 15 | |||||||||||
Consumption(L/100km) : 20 / 35 | 30-40 | |||||||||||
Cab | HOWO 76 New face cab(one bed,with air conditioner), all-steel forward control, 55ºhydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver’s seat and rigid adjustable co-driver’s seat, with heating and ventilating system, outer sun visor, adjustable roof flap,with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers. | |||||||||||
PRODUCT CONFIGURATION
SINOTRUK high power engine
HW19710 gearbox
HOWO 76 cabin with one sleeper
SALES AND SERVICE NETWORK
Successful Project
Project in AFRICA
Project in EUROPEAN
Project in EAST-SOUTH ASIA
SIMILAR PRODUCTS
Sales-After Service
We will supply sll spare parts for our trucks.
Shipment
By Roro or Bulk or Flat Rack Container according to your specific requests.
FAQ
Q: Are you Dealer or Factory ?
A: We are the subsidiary factory of Sinotruk and adopt the strict quality control system which the high quality of the truck.
Q: I want to transport the truck by container, is it ok?
A: Yes, it is ok, but we need take apart the truck and you should reinstall in your country.
Q: How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q: I want to be your agent in my country, is that ok?
A: It’s ok, if your quantity is big, we will consider. For the first time 50 units is ok.
Q. How about your company's service, especially after-sale service?
A: SINOTRUK has been in this field for nearly 60 years and has strong production and distribution capability, we can satisfy your demand within 3-7 days. We always do our best to solve all the problems and put our customer's interests in the first place.
Q: What is your payment terms?
A: You can choose to the 30% prepaid and 70% paid before delivery or you can choose the LC 100% at sight.
Q: What is your lead time?
A: Usually it is 15-20 days after deposit received.
A: We are the subsidiary factory of Sinotruk and adopt the strict quality control system which the high quality of the truck.
Q: I want to transport the truck by container, is it ok?
A: Yes, it is ok, but we need take apart the truck and you should reinstall in your country.
Q: How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q: I want to be your agent in my country, is that ok?
A: It’s ok, if your quantity is big, we will consider. For the first time 50 units is ok.
Q. How about your company's service, especially after-sale service?
A: SINOTRUK has been in this field for nearly 60 years and has strong production and distribution capability, we can satisfy your demand within 3-7 days. We always do our best to solve all the problems and put our customer's interests in the first place.
Q: What is your payment terms?
A: You can choose to the 30% prepaid and 70% paid before delivery or you can choose the LC 100% at sight.
Q: What is your lead time?
A: Usually it is 15-20 days after deposit received.
