Product Description
DG32K2 32m Aerial Ladder platform Fire Fighting Truck.
DG32K2 aerial ladder fire truck with features of flexible, strong adaptive capacity of site, quick rescue speed and high technical security It is widely used for fire-fighting and rescue operation of mid-rise buildings in cities and towns, mines, oil field and factories, it is the necessary equipment to put out fires in mid-rise buildings, rescue person in distress and property.
Advantages and highlights:
1. DG32K2 chassis adopts Benz chassis with advanced performance and large loading capacity, with sufficient margin of power.
2. The firefighting system is equipped with full functions and the pump gun has excellent performance.
The inlet and outlet and control valves are well equipped and easy to operate.
The inlet and outlet and control valves are well equipped and easy to operate.
3. Various working condition curves control mode can efficiently improves rescuing capability of the fire truck and bring the functions of fire truck into full play.
4. Independent working platform has quick disassembly and reassembly function so as to realize various working conditions.
Specification
Items | Parameters | ||||||||
Size parameters | Boundary dimension | Length | mm | 9650 | |||||
Width | mm | 2500 | |||||||
Height | mm | 3880 | |||||||
Wheel base | mm | 4500 | |||||||
Wheel track | mm | 1998/1830 | |||||||
Front overhang/rear overhang | mm | 1430/2710 | |||||||
Driving parameters | Maximum speed | km/h | 90 | ||||||
Minimum turning diameter | m | 17 | |||||||
Braking distance (full load, initial braking speed 30km/h) m | ≤10 | ||||||||
Approach / departure angle | ° | 16/10 | |||||||
Maximum gradeability | % | 25 | |||||||
Quality parameters | Curb weight | Total mass | kg | 17880 | |||||
First shaft | kg | 6010 | |||||||
Second shaft | kg | 11870 | |||||||
Maximum allowable total mass | Total mass | kg | 18030 | ||||||
First shaft | kg | 6180 | |||||||
Second shaft | kg | 11850 | |||||||
Chassis parameters | Model | ZZ5206N501GE1 | |||||||
Drive type | 4×2 | ||||||||
Manufacturer | SINOTRUK | ||||||||
Engine | Model | MC07.28-50 | |||||||
Emission Standards | National V | ||||||||
Displacement L | 6.78 | ||||||||
Maximum net power | kW | 203 | |||||||
Rated power/speed | kW/(r/min) | 206/2300 | |||||||
Maximum torque/speed | N·m/(r/min) | 1100/1200~1800 | |||||||
Manufacturer | SINOTRUK | ||||||||
Number of leaf springs (front/back) | 3/5 | ||||||||
Tire specifications | 295/80R22.5 | ||||||||
Spare tire specification | 295/80R22.5 | ||||||||
Number of tires (number of spare tires) | 6(1) | ||||||||
Passengers | people | 2 | |||||||
