Характеристики
Product Description
Manufacturer 6x4 34m Small Ladder Vehicles Fire Truck DG34M2.
DG34M2 ladder truck is a kind of compact fire fighting main vehicle which is driven by full hydraulic pressure, full rotation,
combination arm (two groups of telescopic arms + one curved arm), and is mainly based on high altitude rescue and has the function of extinguishing fire.
The vehicle is widely used in high-altitude fire rescue operations in cities, factories, mines, ports, and other places. It is the
first choice for extinguishing high-rise building fires, rescue personnel in distress and rescue of property.
This ladder truck uses advanced electro-hydraulic proportional control technology. The main electrical and hydraulic components are imported, all of the imported hydraulic sealing components and high-precision pipes adopt hydraulic hard pipes. The system has high reliability, stable operation and good micro-motion.
DG34M2 ladder truck is a kind of compact fire fighting main vehicle which is driven by full hydraulic pressure, full rotation,
combination arm (two groups of telescopic arms + one curved arm), and is mainly based on high altitude rescue and has the function of extinguishing fire.
The vehicle is widely used in high-altitude fire rescue operations in cities, factories, mines, ports, and other places. It is the
first choice for extinguishing high-rise building fires, rescue personnel in distress and rescue of property.
This ladder truck uses advanced electro-hydraulic proportional control technology. The main electrical and hydraulic components are imported, all of the imported hydraulic sealing components and high-precision pipes adopt hydraulic hard pipes. The system has high reliability, stable operation and good micro-motion.
Boundary dimension | 12350×2500×4000mm | ||||
Full mass | 32500kg | ||||
Maximum speed | ≥90km/h (electronic speed limit) | ||||
Minimum turning diameter | ≤20m | ||||
Approach angle | ≥17° | ||||
Departure angle | ≥9° | ||||
Maximum gradeability | ≥25% | ||||
Outrigger span | Longitudinal span | 6200mm | |||
Horizontal span | 5850mm | ||||
Work platform load | 400kg | ||||
Maximum working height | 34m | ||||
Maximum operating radius | 21m | ||||
Elevating angle of boom | The elevating angle of telescopic boom is -3°~82° | ||||
The elevating angle of folding boom and telescopic boom is 0°~175° | |||||
Rotation scope | 360° full-rotation | ||||
Spread time of outrigger | ≤25s | ||||
Time for lifting the boom to rated height and rotating 90° | ≤100s | ||||
Maximum slewing speed | 0.5~1.5r/min | ||||
