Характеристики
Product Description
DG100 100m Aerial Ladder platform Fire Fighting Truck.
DG100 aerial ladder fire truck with features of flexible, strong adaptive capacity of site, quick rescue speed and high technical security It is widely used for fire-fighting and rescue operation of mid-rise buildings in cities and towns, mines, oil field and factories, it is the necessary equipment to put out fires in mid-rise buildings, rescue person in distress and property.
Advantages and highlights:
DG100 aerial ladder fire truck with features of flexible, strong adaptive capacity of site, quick rescue speed and high technical security It is widely used for fire-fighting and rescue operation of mid-rise buildings in cities and towns, mines, oil field and factories, it is the necessary equipment to put out fires in mid-rise buildings, rescue person in distress and property.
Advantages and highlights:
1. DG100 chassis adopts Benz chassis with advanced performance and large loading capacity, with
sufficient margin of power.
sufficient margin of power.
2. The firefighting system is equipped with full functions and the pump gun has excellent performance.
The inlet and outlet and control valves are well equipped and easy to operate.
The inlet and outlet and control valves are well equipped and easy to operate.
3. Various working condition curves control mode can efficiently improves rescuing capability of the fire truck and bring the functions of fire truck into full play.
4. Independent working platform has quick disassembly and reassembly function so as to realize various working conditions.
Item | Parameters | |||||
Dimension parameters | Outline dimension | Length | mm | 17000 | ||
Width | mm | 2550 | ||||
Hight | mm | 3960 | ||||
Axle distance | mm | 1700+3300+1350+1350+1450 | ||||
Wheel distance | mm | 2087/2087/2087/1804/1804/2045 | ||||
Front overhang/rear overhang | mm | 2740/3650 | ||||
Front protraction/rear protraction | mm | 172/1288 | ||||
Driving parameters | Max speed | km/h | ≥80 | |||
Minimum diameter of turning circle | m | ≤27 | ||||
Brake distance (full load, initial speed of brake 30km/h) | m | ≤10 | ||||
Approaching angle/departure | ° | ≥10/≥9 | ||||
Max incline capacity | % | ≥30 | ||||
Overall mass | Total mass | kg | 64250 | |||
1 Axle | kg | 8650 | ||||
2 Axle | kg | 8900 | ||||
3 Axle | kg | 8900 | ||||
4.5 Axle | kg | 25900 | ||||
6 Axle | kg | 11900 | ||||
Maximum permissable total mass | Total mass | kg | 64400 | |||
1 Axle | kg | 8800 | ||||
2 Axle | kg | 8900 | ||||
3 Axle | kg | 8900 | ||||
4.5 Axle | kg | 25900 | ||||
6 Axle | kg | 11900 | ||||
Chassis parameters | Category | Class-II | ||||
Driving type | 12×4 | |||||
Manufacturer | Daimler AG | |||||
Engine | Model | OM502 LA.Ⅳ/2 | ||||
Type of fuel | Diesel | |||||
Emission/ Max. Net power | mL/ kw | 15928/405 | ||||
Emission level | National IV | |||||
Manufacturer | Daimler AG | |||||
Leaf Springs Number | 4/4/2+_/5/2+_ | |||||
Specification of tire | 385/55R22.5/315/70R22.5/445/65R22.5 | |||||
Number of tires (Excluding the spare tires) | 16 | |||||
Cab allowed capacity | 2 | |||||
