Factory 72m Hydraulic Airport Ladder Fire Truck DG72
- Категория: Fire Trucks >>>
- Поставщик: Xuzhou,Asiaway,Heavy,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.29 $* | 0.91 $* |
| Aug-18-2025 | 0.63 $* | 0.81 $* |
| Jul-18-2025 | 0.26 $* | 0.99 $* |
| Jun-18-2025 | 0.39 $* | 0.59 $* |
| May-18-2025 | 0.90 $* | 0.88 $* |
| Apr-18-2025 | 0.93 $* | 0.99 $* |
| Mar-18-2025 | 0.14 $* | 0.69 $* |
| Feb-18-2025 | 0.77 $* | 0.95 $* |
| Jan-18-2025 | 0.43 $* | 0.93 $* |
Характеристики
Product Description
DG72 72m Aerial Ladder platform Fire Fighting Truck.
DG72 aerial ladder fire truck with features of flexible, strong adaptive capacity of site, quick rescue speed and high technical security It is widely used for fire-fighting and rescue operation of mid-rise buildings in cities and towns, mines, oil field and factories, it is the necessary equipment to put out fires in mid-rise buildings, rescue person in distress and property.
Advantages and highlights:
DG72 aerial ladder fire truck with features of flexible, strong adaptive capacity of site, quick rescue speed and high technical security It is widely used for fire-fighting and rescue operation of mid-rise buildings in cities and towns, mines, oil field and factories, it is the necessary equipment to put out fires in mid-rise buildings, rescue person in distress and property.
Advantages and highlights:
1. DG72 chassis adopts Benz chassis with advanced performance and large loading capacity, with
sufficient margin of power.
sufficient margin of power.
2. The firefighting system is equipped with full functions and the pump gun has excellent performance.
The inlet and outlet and control valves are well equipped and easy to operate.
The inlet and outlet and control valves are well equipped and easy to operate.
3. Various working condition curves control mode can efficiently improves rescuing capability of the fire truck and bring the functions of fire truck into full play.
4. Independent working platform has quick disassembly and reassembly function so as to realize various working conditions.
Main Performance Parameters of Vehicle | ||||
Boundary dimension: (Length × width × height) | 14920×2500×4000mm | |||
Full mass | 50700kg | |||
Maximum speed | ≥85km/h | |||
Minimum turning diameter | ≤26m | |||
Approach angle | ≥13° | |||
Departure angle | ≥8° | |||
Maximum gradeability | ≥25% | |||
Outrigger span | Longitudinal span | 7000mm | ||
Horizontal span | 7000mm | |||
Maximum platform load | 500kg | |||
Maximum working height | 72m | |||
Maximum operating radius | 25m | |||
Elevating angle of boom | For boom NO. 1, it is 1º to 86º The span of boom NO.2 and boom NO. is -76º to +76º Folding boom and No.2 boom 85º to 180º | |||
Rotation scope | 360° full-rotation | |||
Spread time of outrigger | ≤40s | |||
Time for lifting the boom to rated height and rotating 90° | ≤220s | |||
Maximum slewing speed | 0.2~1.0r/min | |||
Our Service
Pre-Sales Service
* Inquiry and consulting service support.
* Sample testing support.
* Visiting our Factory.
After-Sales Service
* Training installation and operating.
* Engineers available for overseas service.
