Product Description
DG22C2 22m Aerial Ladder platform Fire Fighting Truck.
DG22C2 aerial ladder fire truck with features of flexible, strong adaptive capacity of site, quick rescue speed and high technical security It is widely used for fire-fighting and rescue operation of mid-rise buildings in cities and towns, mines, oil field and factories, it is the necessary equipment to put out fires in mid-rise buildings, rescue person in distress and property.
Advantages and highlights:
DG22C2 aerial ladder fire truck with features of flexible, strong adaptive capacity of site, quick rescue speed and high technical security It is widely used for fire-fighting and rescue operation of mid-rise buildings in cities and towns, mines, oil field and factories, it is the necessary equipment to put out fires in mid-rise buildings, rescue person in distress and property.
Advantages and highlights:
1. DG22C2 chassis adopts Benz chassis with advanced performance and large loading capacity, with
sufficient margin of power.
sufficient margin of power.
2. The firefighting system is equipped with full functions and the pump gun has excellent performance.
The inlet and outlet and control valves are well equipped and easy to operate.
The inlet and outlet and control valves are well equipped and easy to operate.
3. Various working condition curves control mode can efficiently improves rescuing capability of the fire truck and bring the functions of fire truck into full play.
4. Independent working platform has quick disassembly and reassembly function so as to realize various working conditions.
Boundary dimension | 10190×2500×3800 mm | ||
Full mass | 15325 kg | ||
Maximum speed | ≥90 km/h | ||
Minimum turning diameter | ≤19 m | ||
Approach angle | ≥17° | ||
Departure angle | ≥9° | ||
Maximum gradeability | ≥25% | ||
Outrigger span | Longitudinal span | 5500 mm | |
Horizontal span | 5500 mm | ||
Work platform load | 300 kg | ||
Maximum working height | 22 m | ||
Maximum working range | 14 m | ||
Elevating angle of boom | The elevating angle of telescopic boom is -3°-+80° | ||
The elevating angle of folding boom and telescopic boom is 0°-+175° | |||
Rotation scope | 360° full-rotation | ||
Spread time of outrigger | ≤30 s | ||
Time for lifting the boom to rated height and rotating 90° | ≤150 s | ||
Maximum slewing speed | 0.5~1.5 r/min | ||
Fire fighting gun | Model | PSKD40D | |
Rated flow | 40 L/s (±8%) | ||
Rated pressure | ≤0.9 MPa | ||
Range | ≥65 m | ||
