High-speed disposable syringe automatic assembly machine Syringe production machine

Product Description



Product function

      This equipment is suitable for the syringe assembly. It adopts PLC control system to automatic feeding, automatic assembly,automatic loading  ; it greatly improves production efficiency, reduces workers and reduces costs.



High-speed disposable syringe automatic assembly machine Syringe production machine parameter details



Function	assembly
Application	syringe
Type	automatic machine
Production efficiency	3600-7200 pcs/hour
Power supply	220V 50/60Hz/5.0KW
Sizes	2800mm (L) x 2400mm (W) x 1710mm (H) (for reference only)
Air volume	200L/min
Weight	800Kg
Air supply	0.5-0.7Mpa
Feeding mode	Vibrating feeder





 Machine Structure:

1. Electronic control: touch screen, PLC control;

2. Gas into components: cylinder drive, optical fiber sensor;

3. The structure sliding part is made of high speed steel, which is stable wear and good fixity;

4. One year warranty;

5. Alarm indication;

Main Features

1. This series machines is designed and manufactured specifically for the syring assembly industry.

2. Automatic detection, automatic start when material is detected, automatic stop when lack of material.

3. Automatic counting , set output.

4. Using the touch screen, intuitive interface, simple and safe operation.

5. Abnormal shutdown, automatic alarming when reporting abnormal information.



    Can be designed and customized for customers, to a greater extent to meet the technical needs of different products.
